6300v high voltage AC alternator (JFG5002-6/6300 800kw)Introduction:
This high voltage AC Alternator can be used in high -atituld field , it can work constantly 72hours ,and the power capacity can be reach to(800-1000KW, power factory0.95 ,can meet different customers request.
1 |
Type of generator |
JFG5002-6/6300 |
2 |
Rated output(kVA) |
800 kVA |
3 |
Rated voltage |
6300 V |
4 |
Rated current |
73.3 A |
5 |
Rated frequency |
50 Hz |
6 |
Power factor |
0.8 |
7 |
Rated speed |
1000 r/min |
8 |
Efficiency |
92.6 % |
9 |
Phases |
3 |
10 |
Type of connection |
Three-phase Y |
11 |
Type of excitation |
Digital automatic voltage regulator (DAVR) |
12 |
Grid-connected operation |
Mode on Voltage Droop or PF or Var |
12 |
Degree of insulation |
F |
13 |
Degree of protection |
IP23 |
14 |
Type of cooling |
Cooling by oneself fan |
15 |
Type of mounting |
IM B3 |
16 |
Moment of inertia |
36 kgm 2 |
17 |
Temperature of environment |
≤40degree |
18 |
Direction of rotation |
()Clockwise running when viewed from the drive end |
19 |
The direction of cable terminals |
()right or left when viewed from the drive end |
