| Prod Model: |
GDD15S |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Customer Service: |
2 Year International Warranty Service |
| Specialize: |
100% Famous Material |
| Stroke: |
Four Stroke |
| Type: |
Basic Diesel Generator |
| Cooling Method: |
Water Cooling |
| Installation Method: |
Fixed |
| Output Type: |
AC Three Phase |
Product Description
Parameter:
Power Factor: 0.8(lagging)
Protection Standard: IP21-IP23
Model of Connection: 3 phase 4 lines
Insulation Grade: H
Frequency Drop(%): ≤ 0.5
Transient state frequency deviation(%): (advertised power) +10~-7
Frequency Recovery Time(S): ≤ 3
Voltage Recovery Time(S): ≤ 4
Waveform Distortion(%): ≤ 5
Features:
High fuel efficiency: Fewer fuel consumption at leading level than other competitive products.
The turbocharger with waste gated design: Optimizes operation across the torque curve resulting in excellent low-end torque.
Compacted yet durable and dependable engine: Cummins engines contain up to 40% fewer parts than competitive engines in its class. This results in a better power-to-weight ration, a less chance of failure and lower repair cost.
Advanced design and manufacturing: Make the engine delivers superior performance and lower cost than competitive engines.
Excellent cold start performance: Optional assistant cold starter with improved 6.6KW starter and intake air heater.
Excellent performance and advantage: Adopt advanced design to achieve higher horsepower and lower weight.
Deutz diesel engine assy &accessories DEUTZ: BFL413, BFL513, FL511, FL912, BFL913, BFL913C, BFM1011, BFM1012, BFM1013, BFM1015, BFM2012, BFM2013
A. Excellent features for deutz diesel generator set
1)World most famous brand diesel engine: Deutz.
2)World most famous brand AC alternator: Stamford, Leroy Somer & MVC brand for your selection.
3)World most famous brand control system: The British Deepsea & Shen Zhen Smartgen
Control Panel for your selection.
4)World most famous brand ATS: French Socomec ATS.
5)Engine and alternator shall be mounted on a same frame steel skid, Buit-in damper for
Anti-vibration.
6)Small size, low weight, low consumption and radio interference, easy to operating, installation
And maintenance.
7)Advanced and reliable control module: Electronic or Automatical Starting.
8)Three phase voltage available: 208V & 220V & 230 & 240V & 380V & 390V & 400V & 415V &
440V & 460V & 480V.
9)Full range protect function and alarm shutdown feature.
10)12 months warranty from ex-factory date(1300 running hours at least), whichever comes first.
11)CE approval.
B. Deutz Diesel Engines
Designed with Gemany Technology
Deutz water cooled diesel engines, oil and fuel filter fitted, water seperator, lude-oil drain valve fitted
Enviromental Friendly
The Emission meet Euro-V standard
Compact Size
For easy of installation and easy access for routine maintenan
| Genset Model | GDD15 |
| Rated Output | 12Kw/15Kva |
| Standby Output | 13Kw/16Kva |
| Voltage | 220/230/240/380/400/440V |
|
| Frequency | 50Hz/60Hz |
| Speed | 1500rpm/1800rpm |
| Type | 3phase 4wire |
| Protect Class | IP23 |
| Starting system | Electric starting |
Engine data
| Engine Model: | F2L912 |
| Engine Type: | 2 Cylinders,in Line |
| Aspiration Method: | Natural Aspirated |
| Displacement: | 1.88L |
| Bore*Stroke | 100mm*120mm |
| Ratio | 17:1 |
| Rated Power: | 20kW/2350rpm |
| Torque/Speed: | 125N.m/1450rpm |
| Fuel consumption at power rating 110% | 238g/kwh |
| Fuel consumption at power rating 100% | 238g/kwh |
| Fuel consumption at power rating 75% | 238g/kwh |
| Fuel consumption at power rating 50% | 238g/kwh |
| Cooling Method: | Air-cooled |
| Lubrication capacity | 8L |
| Control System | Mechanical/Electronic Governor |
| Emission Standard: | Euro II |
| Electric system | 12/24V |
| Size(L*W*H): | 678mm*704mm*872mm |
| Net Weight: | 245KG |
