| Prod Model: |
R-P13S |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia |
| Engine Model: |
403D-15g |
| Engine Brand: |
Powerd by Perkins |
| Type: |
Basic Diesel Generator |
| Installation Method: |
Fixed |
| Stroke: |
Two Stroke |
| Cooling Method: |
Wind Cooling |
| Output Type: |
AC Three Phase |
Product Description
RCG POWER, the Chinese renowned manufacturer located in Wuxi, China, as the biggest OEM partner for Cummins generator set, we've been in this industry for over two decades, any enquiry or interest to know more, pls contact us
Our warranty term:
1. One year or 1000 running hours since the Date of Supply (subject to whichever reaches earlier)
2. During the warranty period, we'll cover any quality issues except for those caused by user's incorrect operation.
Trustworthy Manufacturer for Cummins, Doosan, Volvo, Yanmar, MTU, MAN Diesel generator set
Generating Set Specification
| MODEL | R-P13S |
| PRIME POWER (KVA/KW) | 13/10 |
| STANDBY POWER(KVA/KW) | 14/11 |
| Rated voltage(V) | 400/230 |
| Rated speed(rpm) | 1500 |
| Rated frequency(Hz) | 50 |
| Power factor | 0.8 |
| Ambient temperature(ºC) | 40 |
| Altitude(m) | 1000 |
| Connection type | 3 phase 4 wires |
| ENGINE MANUFACTURER | PERKINS |
| Model | 403D-15G |
| Rated Power(kW) | 20.3 |
| No. of cylinders & configuration | In-Line 4 cylinders |
| Method of operation | 4-stroke |
| Speed regulation | Mechanically governor |
| Starting system | DC 12V Electronic start |
| Cooling method | Closed-circuit cooling system |
| Total displacement(L) | 2.216 |
| Compression ratio | 23.3:1 |
| Bore×Stroke(mm) | 84×100 |
| 100% Load fuel consumption(L/h) | ≤4.3 |
| ALTERNATOR MANUFACTURER | STAMFORD |
| Number of Phase | 3 |
| Connection Type | 3Phase and 4Wires |
| Number of Bearing | 1 |
| Power Factor | 0.8 |
| Protection Grade | IP23 |
| Terminal | 12 |
| Winding/ Pitch | 100% Copper 2/3 Pitch |
| Cooling Fan | Cast alloy aluminum |
| Exciter Type | Brushless, Self-Exciting |
| Insulation Class, Temperature Rise | H/H |
| Telephone Influence Factor( TIF) | TIF <50 / THF<2% |
| Total Harmonic TGH/THC | <1.5% at no load / <5% at load |
| Voltage Regulation, Steady State | ≤±1% |
| Sustained Short-Circuit Current | 300%(3 in):10s |
| CONTROL SYSTEM | DSE SERIES |
Ruichang Gold Generating Equipment (Wuxi) Manufacturing Co., Ltd., established in 1982, is a manufacturer of a wide variety of diesel generator sets and portable power supplies. We are able to offer high quality diesel generator sets with imported engines, trailer-mounted power stations, mobile and container power stations, and even bunker power generator sets.
Our products are suitable for such industries as defense, telecommunications, transportation and natural resources. Additionally, buildings including hospitals, banks, and offices may use our power stations as either a mobile or stationary backup power supply. We accept special orders from clients and are able to meet all kinds of special technical requirements.
As a Sino-foreign joint-venture (Ruichang Gold Co., Ltd. Hong Kong and Wuxi Ruichang Electro Equipment Plant), we aim for the highest quality standards. We are ISO9001 certified and our products are manufactured according to strict internal quality control standards.
Our company principle is "Customers and credibility first" and always provide superior services and free consultation. Whether your inquiries are regarding product selection, systems integration, generator room designs or other technical details we will be happy to assist you with your needs.
We welcome both new and existing customers to come take a look at our current lineup and hope that you will choose our brand of competitively priced quality products. Please contact us for further details and we will promptly answer any questions you may have.
