150kw/187.5kVA Deutz Electric Generator

Name: 150kw/187.5kVA Deutz Electric Generator
Brand: aboutgenerator.com
SKU: 698570262
Availability: InStock
Rating: 4.9 (35 reviews)

Price:	US $ 11184/Piece
Trade Terms:	FOB,CFR,CIF
Min Order:	1/Piece
Pay Type:	L/C,T/T,Western Union

Contact Supplier

Weifang Huaquan Power Machinery Co., Ltd.

Showroom Product Company Profile

Prod Model:	HQ150GF
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Rated Power:	150kw/187.5kVA
Certificates Of Engine:	GB/T2820-97,ISO8528, ISO9001
Warranty:	18months
Rated Voltage:	220,110,230,240,380,400,440,415V
Optional:	Silent/ATS/Trailer
Starting Method:	Key Starting
Dimension:	24508001600mm
Color:	as Your Requset
Stroke:	Six Stroke
Type:	Basic Diesel Generator
Cooling Method:	Water Cooling
Installation Method:	Portable
Output Type:	AC Single Phase

Product Description

150KW/187.5KVA DEUTZ electric generator

Genset technical data

Prime power	150kw
Standby power	165kw
Rated speed	1800 rpm
Output frequency	60 hz
Phase	3
Rated voltage	400 v
Noise db(a) @7m	100
Engine model	Wd615 64d-15
Alternator model	Mp-150-4

Deutz diesel enginetechnical data

Engine model	Wd615 64d-15
Configuration	4 cycle,6 cylinders in line
Aspiration	Turbocharged
Bore×stroke	126x130
Rated speed	1800rpm
Displacement	9.726l
Prime power	160kw
Speed governor	Electrical
Cooling system	Water-cooled , 40°c radiator as standard, 50°c is optional.
Speed stability (%)	≤5%
Fuel consumption at 100% load	208
Starter motor	Dc24v,

Marathon alternator technical data

Alternator model	Mp-150-4
Alternator manufacturer	Marathon
Exciter type	Single bearing, brushless, self-excited
Rated output prime power	150kw
Rated speed	1800 rpm
Rated frequency	60 hz
Phase	3
Rated voltage	440 v(available with customer requirements)
Power factor	0.8
Voltage adjust range	≥5%
Voltage regulation nl-fl	≤±1%
Insulation grade	H
Protection grade	Ip23

Huaquan Power is specialized in producing diesel generator set, diesel generator, generator set, diesel generating set, generating, generating set, generator diesel, power generator, gas generator, nautral gas generator, eletric generator, alternator, diesel engine etc. We have open frame generator, automatic generator, trailer generator, silent/soundproof diesel generator, water pump etc. And the brands include Cummins, Perkins, Deutz, Steyr, Isuzu, Ricardo, Yuchai, as well as famous brands of alternator, such as Stamford, Faraday, Leroy-somer, Qiji. Power ranges from 3kw to 1000kw

Huaquan Power Mchinery Co., Ltd, located in diesel engine manufacturing powerhouse-Weifang, the capital of kites.

Huaquan Power has more than 500 employees worldwide and it has four advanced production lines, sophisticated testing equipment, complete quality management system, and marketing all around the world in the past 10 years, such as Southeast Asia, the Middle East, Africa and other regions.

Huaquan Power ensures that providing the energy saving, environment protection, high quality and reliable diesel engine and generators, to ensure user satisfaction and rest assured! We sincerely look forward to your cooperation!
