Material:
Carbon Steel
Single Flow Rate:
6-300m3/H
Design Pressure:
7.5-16 Bar
Water Inlet Pressure:
2.5-3 Bar
Filter Precision:
20-100microns
Product Description
20-100 Microns Above Ground Pool Quartz Sand Filter Pump
Quartz sand filter removes impurities from raw water to achieve water reuse. Filter is automatic operation and back-flushing, under control system of dp-switch (pressure drop), butterfly and PLC control system.
1. How does the quartz sand filter works Raw water passes inside water distributor into filter media layer (quartz sand), which let impurities stay at sand layer. Clean water flow out stably from water collector. When the pressure drop reaches the given value, the cleaning cycle is started. The rinse control start working at pressure drop value at 0.05-0.15MPa, return to 0.02-0.04MPa after back flushing. Quartz sand inside tank mixed with coarse and fine sands. They are allocated above water distributor averagely. Even in back flushing, water consumption is little. Tank inside has rubber line and plastic line for option. It is for anti-corrosion, which ensure a tank can be used 10-20years. The completed filter control system has finished already in factory.
2.Where to use quartz sand filter Swimming pool, hotel spa, water entertainment, aquarium, fish farm Irrigation in agriculture Drinking water pre-treatment Industrial recycled water, central air-condition system
3.Attentions in using 1. When quartz sand filter first into use, users should clean sand firstly, after that to start filtration. 2. Turn all operating valves slowly, to avoid water impact. 3. Keep sharp or hard things away from filter. 4. Keep away from fire and high temperature. 5. Make sure sand is clean when not using.
4.How to install? Before installing a quartz sand filter, please make sure the ground is strong and even. The space is big enough for connecting pipes, valves and repair. The filter needs changes sands after using some time. Follow below steps one by one: 1. Take down control valve 2. Pour sand into tank, by covering a protective cover at the inlet to avoid sand inside After replacing new sand, return control valve, connect tightly. Remember there's a pressure gauge, but not fasten it tightly. Make sure each pipe connection is correct and no leak.
No
Model
Diameter (mm)
Height (mm)
Connect Diameter(mm)
Filter area (M2)
Recommend Flow (m3/H)
1
QLQ 1400× 1700
1400
1700
100
1.54
45 to 75
2
QLQ 1600× 1800
1600
1800
150
2.01
60 to 100
3
QLQ 1800× 1900
1800
1900
150
2.54
75 to 125
4
QLQ 2000× 2000
2000
2000
150
3.14
95 to 155
5
QLQ 2200× 2000
2200
2000
150
3.8
115 to 190
6
QLQ 2400× 2100
2400
2100
150
4.52
130 to 210
7
QLQ 2600× 2400
2600
2400
150
5.3
145 to 225
8
QLQ 2800× 2500
2800
2500
200
6.15
155 to 240
9
QLQ 3000× 2600
3000
2600
200
7
170 to 255
WELCOME TO INQUIRE, WE WILL OFFER YOU THE BEST ITEMS !
