| Prod Model: |
DWG6LE |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Power: |
2.5kw/4.6kw |
| Type: |
Spot Welders |
| Current: |
Alternating Current |
| Application: |
Construction |
Product Description
Instrustaions:
Changzhou ETK Power Machinery Co., Ltd is an export manufactory, Our products involve diesel generator, gasoline engines, air-cooled diesel, diesel welder generator, water pumps, air compressors, pressure washers and other various machinery.
|
Model |
open type |
|
DWG6LE |
|
Frequency(Hz) |
50/60 |
|
Voltage(AC)(V) |
120/240;220;230;240 |
|
Rated Power(Kw) |
2.5(4.6) / 2.7(5.0) |
|
Current(A) |
11 |
|
Power facotr(cosφ) |
1 |
|
Electric welding voltage in idle(V) |
55-65 |
|
Rated current for electric welding(A) |
160-180 |
|
Working voltage for electric welding(V) |
25-30 |
|
Electric welding load lasting rate |
50% |
|
Regulating rang of electric welding current(A) |
80-180 |
|
Engine Speed(rpm) |
3000/3600 |
|
Net weight(kg) |
116 |
|
Starting system |
Recoil manual start/optional electric start |
|
Engine model |
ETK186F(A)(E) |
|
Type |
Single cylinder,vertical,direct injection,5-stroke,air cooled diesel engine |
|
Continuous Output(Kw) |
5.7/6.6 |
|
Maximum Output(Kw) |
6.3/7.34 |
|
Bore × Stroke(mm) |
86*70/86*72 |
|
Displacement(cc) |
406/418 |
|
Fuel Tank Capacity(L) |
15 |
|
Packing dimensions(L×W×H)mm |
785*550*635 |
|
Lube-oil Capacity(L) |
1.65 |
|
20FT container (pcs) |
99 |
