| Prod Model: |
HZZ9407GHY |
| Markets: |
Eastern Europe,Southeast Asia,Africa,Oceania,Eastern Asia |
| Tank Material: |
Alluminum Alloy 5083 |
| Full Capacity: |
22000L |
| Total Mass: |
24000kg |
| Rated Payload: |
Approx. 12000kg |
| Chassis: |
Ud Nissan |
| Port Of Delivery: |
Shanghai/Ningbo |
| Truck Type: |
Tanker Truck |
| Type: |
Other Diesel Heavy Goods Vehicle |
| Transmission Type: |
Manual |
| Power: |
Diesel |
| Emission Standard: |
Euro 3 |
| Tank Volume: |
15001-30000L |
| Horsepower: |
251-350hp |
| Storage: |
Oil |
| Tire Type: |
Solid Tire |
| Tire Certification: |
ISO |
| Tire Design: |
Tubeless |
| Condition: |
New |
| Load Capacity: |
12t |
| Drive Wheel: |
6wd |
| Seats: |
2-3 |
Product Description
2015 hot sale Aluminum Alloy oil Tank Truck
Quick Details:
1.Name:oil tank truck
2. Tank material : Aluminum Alloy 5083
3.Drive Wheel:6x4
4. Horsepower: 235(320HP)
5.Chassis :Dongfeng Nissan Diesel
7.Full Capacity: 22500L
BASIC SPECIFICATIONS:
Storage Properties
Gasoline, light diesel, kerosene etc.
Functions
As a transportation product, it register full of functions such as: oil transportation, refueling
tender, fixed-container refueling, and portable pump.
Be popular in
The oil fuel series classified as general refueling vehicles (with oil pump system) and fiscal tank vehicles, widely used in oil station and transportation companies.
Advantages
The liquid truck has reasonable structure, reliable performance, beautiful appearance, and simple operation etc. merit.
Product Description:
As to the whole tank truck, usage for transport the gasoline, light diesel oil, petroleum and other non-corresive fluid, we use second-class Chinese and international chassis to refit, such as Faw
Group, Dongfeng, Sino Truck, UD Nissan, Auman, Isuzu etc.
| Model | HZZ9407GHY |
| Outer dimension(mm) | 10500×2490×3850 |
| Tank Effective Volume (m3) | 38 |
| Transporting Medium | Methanol/Gas/Diesel |
| Wheelbase (mm) | 5300+1320+1320 |
| Number of Axle | 3 |
| Tare weight(Kg) | 9500 |
| Payload(Kg) | 30500 |
| Spec. of Tyre | 425/65R22.5,445/65R22.5 |
| Number of spring steel plate | 7/7/7,4/4/4,Air suspension |
Applications:
2015 hot sale Aluminum Alloy oil Tank Truck is widely used in various transportation units, fuel companies and other logistic industries.The fuel tank transportation series, as to the whole tank truck, usage for transport the gasoline, light diesel oil, petroleum and other non-corresive fuel properties, rarely impact the damage for oil pump, generator, refullering gun,etc
Competitives:
1. Chassis has such merits: High-power, Lighten weight, Nice performance, widely used in oil station
and some logistic companies.
2. We use OEM fittings, an international and national famous brand, makes the tanker solid and
durable, and reduce the cost to operate and maintain.
3. The liquid truck is produced with the special equipments such as automatic welding machine(8m) and CNC plasma cutting and automatic submerged arc welding forming which can realize welding
by one side in shape by two sides, having the merits of stable quality, less cost, and good-looking.
Name |
Standard Configuration |
Chassis |
DF Nissan Diesel |
Drive Type |
6x4 |
Engine Power |
235(320HP) |
Total mass |
24000kgs |
Curb mass |
11905kgs |
Tank material |
Aluminum Alloy 5083 |
Manhole Cover |
Aluminium alloy, 20" self-latching manhole cover, with air-van. |
Outlet port |
Pneumatic sea valve , fix all aluminum alloy connector. |
Pump System |
Optional |
Others |
Pipe box, ladder, walkway platform, toolbox, Fire Extinguisher,
etc accordance by manufacture standard.
|
Hangzhou Special Automobile Company, a concrete equipment and tank transport truck manufacturer and supplier, was founded in 1954, China. We produce an exceptional concrete pump truck, concrete mixer truck, oil tank truck, bulk cement tank trailer, tank container trailer, and garbage truck, just to name a few of our outstanding products.
Hangzhou is a subsidiary of Jinggong Science and Technology Company which has a registered capital of 15.4 million USD. We are located in Hangzhou Economic Development Zone, which is a high national level and new technology development zone in Hangzhou city, Zhejiang province, China. This location offers us easy access to Shanghai and ningbo port, which greatly reduces transportation cost for clients and us.
Our factory covers over 60000m2, with a building area of 15, 000m2. We have a professional technical team composed of experts in the mechanical, electrical, hydraulic, and automobile engineering industries. These highly skilled and expert professionals are committed to the design and development of a variety of special vehicles. Our production equipment, including our plasma CNC cutting machines, CNC bending machines, shearing machines, and other facilities, that
Acquired from reliable suppliers and offers dependable and precise performance. This state-of-the art production equipment helps us manufacture our superior concrete pump truck, tank truck, tank trailer, and other top-quality products.
In order to continuously improve our technology, we collaborate with internationally famous associates and Chinese top ranked universities. Furthermore, our tank-mounted concrete pump, refueling tank truck, chemical liquid tank trailer, and other trucks are CCC certified, and our company is ISO9001: 2000 and ISO 14001: 2008 certified. Therefore, customers can feel secure in purchasing our outstanding vehicles.
