| Price: | US $ 7229-50000/Set |
|---|---|
| Trade Terms: | FOB,CFR,CIF |
| Min Order: | 1/Set |
| Pay Type: | L/C,T/T,Western Union |
| Prod Model: | 4B3.9-G1 |
|---|---|
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Frequency: | 50/60Hz |
| Rated Power: | 8-2050kVA |
| Rated Voltage: | 220/380V, 230/400V |
| Rated Current: | up to Voltage |
| Noise: | Less Than 75db/107db |
| Control System: | Intelilite/Deepsee |
| Alternator: | Stamford |
| Insulation Grade: | H |
| Fuel Comsuption: | Low |
| Quality: | High |
| Type: | Basic Diesel Generator |
| Stroke: | Four Stroke |
| Output Type: | AC Three Phase |
| Installation Method: | Fixed/Portable |
| Cooling Method: | Air/Water |
| Conditions Of Use: | Land/Marine/Trailer |
Portable GeneratorType of Electric Power Generator | ||||
CONFIGURATION | DIESEL GENERATOR SET | ENGINE | ALTERNATOR | CONTROL PANEL |
Breif Introduction |
advanced design,reliable performance, long service life time lintelligent control,easy operation, convenient maintenance ldiversified optional function , satisfyingapplicationrequirements
| CUMMINS 6BTA5.9-G2 | STAMFORD UCI274C1 | Self-protecting control panel |
JACA CUMMINS SERISE PRODUCT SPECTRUM DIAGRAM:
Genset Model | Rated power | Engine Type | Alternator Teype |
| J25CS | 20kW/25kVA | 4B3.9-G1 | PI144E |
| J38CS | 37.5kW/30kVA | 4BT3.9-G1 | PI144J |
J50CS | 40kW/50kVA | 4BTA3.9-G2 | UCI224D1 |
J60CS | 48kW/60kVA | 4BTA3.9-G2 | UCI224E1 |
J100CS | 80kW/100kVA | 6BT5.9-G2 | UCI274C1 |
J115CS | 92kW/115kVA | 6BTA5.9-G2 | UCI274D1 |
J130CS | 104kW/130kVA | 6BTAA5.9-G2 | UCI274E1 |
J160CS | 128kW/160kVA | 6CTA8.3-G2 | UCI274F1 |
J181CS | 145kW/181kVA | 6CTA8.3-G2 | UCI274G1 |
J200CS | 160kW/200kVA | 6CTAA8.3-G2 | UCI274H1 |
J250CS | 200kW/250kVA | 6LTAA8.9-G2 | UCDI274K1 |
J312CS | 250kW/312kVA | NTA855-G1B | HCI444ES1 |
J343CS | 275kW/343kVA | NTA855-G2A | HCI444E1 |
J375CS | 300kW/375kVA | NTAA855-G7 | HCI444FS1 |
J450CS | 360kW/450kVA | KTA19-G3 | HCI544C1 |
J500CS | 400kW/500kVA | KTA19-G3A | HCI544C1 |
J590CS | NA | KTA19-G5 | HCI544E1 |
J625CS | NA | KTA19-G6A | HCI544FS1 |
J750CS | 600kW/750kVA | KTA38-G2 | LVI634B1 |
J800CS | 640kW/800kVA | KTA38-G2A | HC1634G |
| J910CS | 720kW/910kVA | KTA38-G2A | HC1634H |
| J1000CS | 800kW/1000kVA | KTA38-G5 | HC1634J |
J1135CS | NA | KTA38-G9 | LVI634F1 |
J1250CS | 1000kW/1250kVA | KTA50-G3 | LVI634G1 |
J1500CS | 1200kW/1500kVA | KTA50-GS8 | PI734C1 |
| Electric Generator with Cummins Power | |||
| Rated Power | 20kw-1200kw/ 25kva-1500kva | Reserve Power | 22kw-13200kw/ 27.5kva-1650kva |
| Frequency | 50/60Hz | Frequency Reduce | ≤ 3% |
| Voltage Regulation | ≥± 5% | Voltage Modulation | 0.3% |
| Engine Brand | Cummins | Alternator Brand | Stamford |
| Rated Speed | 1500/1800rpm | Phase | 3 phase 4 line |
| Governer Type | Mechanical / Electronic Governer | Adjusting Mode | AVR |
| Fuel tank | For 8 to 48 hours running use | Exciter type | Brushless, self-exciting |
Electric Generator with SDEC Power | |||
| Rated Power | 50kw-640kw/ 62.5kva-800kva | Reserve Power | 55kw-700kw/ 68kva-880kva |
| Frequency | 50/60Hz | Frequency Reduce | ≤ 3% |
| Voltage Regulation | ≥± 5% | Voltage Modulation | 0.30% |
| Engine Brand | SDEC | Alternator Brand | KAIJIELI |
| Rated Speed | 1500/1800rpm | Phase | 3 phase 4 line |
| Governer Type | Electronic Governer | Adjusting Mode | AVR |
| Fuel tank | For 8 to 48 hours running use | Excitertype | Brushless, self-exciting |
| Electric Generator with Perkins Power | |||
| Rated Power | 6kw-1640kw/ 7.5kva-2050kva | Reserve Power | 6.6kw-1804kw/ 8kva-2255kva |
| Frequency | 50/60Hz | Frequency Reduce | ≤3% |
| Voltage Regulation | ≥±5% | Voltage Modulation | 0.30% |
| Engine Brand | Perkins | Alternator Brand | Stamford |
| Rated Speed | 1500/1800rpm | Phase | 3 phase 4 line |
| Governer Type | Mechanical / Electronic Governer | Adjusting Mode | AVR |
| Fuel Tank | For 8 to 48 hours running use | ExciterType | Brushless, self-exciting |
COMPANY INFORMATION:
JACA is specialized in Industrial generator industry,providing global customers with high quality, stable,and reliable green power and offering each customer personlized comprehensive solution through excellent generator .
Main products are Industrial generator of various types such as open type,soundproof type,movable type,container type,waterproof type.Natural gas generator set and methan generator set are also available.Independent diesel engine of Sdec,Cummins,Perkins and seperated alternator of Stamford,Leroy Somer,Marathon are in stock as well.
Accessories for generator control system are stored for emergency use and convenience.Our after-sale service department is authorized by Sdec and Shanghai Hino
SERVICES:
1.Before-sale Service: we provide detailed product technical parameters for equipment choosing and system designing.
2.In-sale Service: 24 hours online support technical guidance, remote installment, maintenance ,technique instruction.
3.After-sale maintenance service:We create files for users and provide them follow-up service,regular return visit and permanent maintenance.
4.Spare parts supply:We provide all kinds of spare parts and technical support.
5.Service quality assurance:our sale staffs are all experience and professional,who can provide the most proper system design and optimized equipment for the customers.
