| Prod Model: |
EDT250PS |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Installation Method: |
Fixed |
| Stroke: |
Four Stroke |
| Cooling Method: |
Water Cooling |
| Output Type: |
AC Three Phase |
| Type: |
Silent Mobile Trailer Diesel Generator |
| Speed: |
1500rpm /1800rpm |
| Conditions Of Use: |
All Types Available |
| Usage: |
All Types Available |
| Landuse Type Of Unit: |
All Types Available |
Product Description
Product Features:
MOBILE TRAILER DIESEL GENERATOR MORE CONVENIENT FOR OPERATION AND USAGE
World Top Diesel Engine PERKINS used
l
lWorld Top Alternator STAMFORD used
l
lOriginal DEEP SEA intelligent monitoring system used
l
lHigh Quality AISIKAI ATS as optional
l
lSilent Performance, Compact and Ingenious design
l
lProfessional R&D Team and years of leading manufacturing & assembling experience of high quality generating setsSuper Absorbent Materials used The generating set canopy are ultra noise deducting structure design whose vendor are
also producing for reputable player such as Kohler and etc.
Compact design can minish unit dimension, and reduce logistic cost Easy transportation, convenient operation and excellent access for maintenance.
Oversized Muffler design
uDigital Monitoring system independently designed for ease operation, versatility and exam-maintenance.
Complying with the security and safety standards
| Genset Model | EDT250PS |
| SET | Rated power(Kw/kva) | 200/250 |
| | Frequency(Hz) | 50 |
| | Pahse | 3 |
| | Voltage(V) | 230/400 |
| | Current(A) | 360.8 |
| | Fuel capacity(L) | 400 |
| | Fuel consumption(L/Hour)
| 55 |
| | Dimension (mm) | L | 3600 |
| | | W | 1350 |
| | | H | 1900 |
| | Weight(kg) | 2700 |
| | Noice level for silent type (Db/7m) | 72 |
| ENGINE | Model | S6TA/D |
| | Prime power(kw/kva) | 220/275 |
| | Cylinders | 6 |
| | Bore× stroke(mm) | 126x130 |
| | Intake Method | Turbocharging intake |
| | Displacement(L) | 9.73 |
| | Speed governing | Electronic governor |
| | Cooling starting method | Water cooling |
| ALTERNATOR | Model | DG274K14 |
| | Rated power(kw/kva) | 200/250 |
| | Insulation class | H |
| | Alternator enclosure | IP23 |
| THIS SET COULD BE OPERATED ON 100% OF THE POWER CAPACITY AT ALTITUTE OF 1500M, AMBIENT TEMPERATUR OF 50° C. WE RESERVE THE RIGHT TO EXPLAIN THE TERMS OF THIS SPECIFICATION. |
