| Prod Model: |
WKV-3000 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Size(Height / Diameter): |
3.5/3.2(M) |
| Blades Material: |
Aluminum Alloy |
| Generator Type: |
AC, 3 Phases |
| Controller Output Voltage: |
48/96V |
| Rated Power: |
3000W |
| Start Up Wind Speed: |
1.5m/S |
| Rated Wind Speed: |
13m/S |
| Survival Wind Speed: |
60m/S |
| Controller Braking System: |
3-Phase Short Circuit by NFB Brake |
| Working Temperature: |
-30~50 |
| Number Of Blade: |
Three Blade |
| Rotating Shaft: |
Vertical |
| Stress Way Of Blade: |
Resistance |
Product Description
1 product descripyion
PARAMETERVERTICAL WIND TURBINE MODEL NUMBER
WKV-5000
Rated Power5KW
Size(Height / Diameter)3.53/3.9(M)
Blades Materialaluminum alloy
Start-up Wind Speed1.5m/s
Minimum Power Generation Wind Speed2.5m/s
Cut-in wind speed4m/s
Rated Wind Speed13m/s
Cut out Wind Speed15m/s
Survival Wind Speed60m/s
Generator TypeAC, 3 phases
Controller Output Voltage 48/96V
Controller Braking System3-Phase short circuit by NFB brake
Ambient Temperature. -30~50 ° C
2 the benefit of the wind turbine
Lowest cut-in wind speed
No noise, no vibrations
Adaptable for hybrid solutions
Permanent power supply
Technically advanced Maglev generator
Best price-performance ratio All weather resistant
Independent of wind direction
Suitable for roof fixation
Maintenance-free
Safety for people and nature
Useage
· Household, Garden, farm eolic vertical wind turbine generator, Off grid and on grid power system
· Telecom sites.
· Rural electrification programs. Island, sentry, island, sight lighting
· Make wind -solar hybrid power system
Our Service
1. Reply inquiry in 24 hours.
2. Please kindly inform us which items you are interested & the reasonable price will be provided you upon receipt of your new inquiry ASAP.
3. Answer your question detailed
4. Solved the problem with you during using our products
| PARAMETER | VERTICAL WIND TURBINE MODEL NUMBER |
| WKV-3000 |
| Rated Power | 3KW |
| Size(Height / Diameter) | 3.5/3.2(M) |
| Blades Material | aluminum alloy |
| Start-up Wind Speed | 1.5m/s |
| Minimum Power Generation Wind Speed | 2.5m/s |
| Cut-in wind speed | 3.5m/s |
| Rated Wind Speed | 13m/s |
| Cut out Wind Speed | 15m/s |
| Survival Wind Speed | 60m/s |
| Generator Type | AC, 3 phases |
| Controller Output Voltage | 48/96V |
| Controller Braking System | 3-Phase short circuit by NFB brake |
| Ambient Temperature | .-30~50 °C |
More Model
| Model No. | Output Power(W) |
| WKV-100 | 100W |
| WKV-200 | 200W |
| WKV-300 | 300W |
| WKV-400 | 400W |
| WKV-600 | 600W |
| WKV-1000 | 1KW |
| WKV-2000 | 2KW |
| WKV-3000 | 3KW |
| WKV-5000 | 5KW |
