| Prod Model: |
FD4-3000W |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Rotating Shaft: |
Horizontal |
| Number Of Blade: |
Three Blade |
| Stress Way Of Blade: |
Resistance |
| Phase: |
3 Phrase |
Product Description
Model: FD4-3000w
Rotor Diameter: 4m
Number of Blades: 3PCS
Material of Blades: Fibre glass expoxy
Cut-in wind speed: 3m/s
Working wind speed: 4-30m/s
Survival wind speed: 50m/s
Rated wind speed: 12m/s
Rated rotate speed: 280r/min
Rated output power: 3kw
Max output power: 4kw
Type of tower: Guy wire tower or tilting up tower
Type of generator: Permanent-magnet 3 Phase AC
Speed regulation method: Yaw+auto brake
Working voltage: DC48/DC240V or special request
Operating Temperature: -40--+60
Tower height: 8m, 12m, 15m or special request
Wind turbine main body weight: 220kg
Measurement(CBM): 2
Life span: 15 years;
Warranty: 2 years
Working system: Off-grid working system
On grid working system
You can take the whole working system from us, also you can take any parts of the system from us. We will ensure you system works well.
If there are any question, pls let us know. We will give you quickly and professional response!
Ningjin huaya industry Co., Ltd. is specialized manufacture of small wind turbine generator.
Form the first 50W, 100W wind turbine to 300W-20kw wind turbine, we past 15 years. Now we have the steady off-grid working system, 1kw, 2kw, 3kw, 5kw, 10kw, 20kw on-grid working system. To provide the steady system is our aim.
Blades:
The blade form is chosen by wind tunnel test. The aerofoil with the highest wind speed utilization ratio is used. The wind energy transfer efficiency can reach 0.42.
Generator:
ND-fe-b permanent magnet. Packaged type tangential grinder magnetic circuit rotor; High magnetic flux density, small cubage, good manufacturing technics and high capability.
Adopt Sweden SKF bearing.
Close transmission slip ring, the cable will not enlace
Tower:
Tower with guy wires, tilting up tower, hydraulic tower, independence tower. It can be designed according to your request.
Now the wind turbine system is working in more than 30 countries. To provide the good, steady system is our aim.
For more products details, pls contract with us! We will provide you quickly and professional feedback.
