South America,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia
Dimension:
5180*1700*2300mm
Alternator:
Leateck/Stamford
Controller:
Smartgen
Insulation Grade:
H
Protection Grade:
IP21-23
Start System:
Electric Start
Type:
Micro-Computer Control Automatic Diesel Generator
Installation Method:
Fixed
Stroke:
Four Stroke
Cooling Method:
Water Cooling
Output Type:
AC Three Phase
Product Description
Product Description
1. Cummins Power diesel generator 2. Standby Power: 688kva/550kw 3. Frequency: 50Hz or 60Hz 4. Market: Nigeria, Ghana, Uganda, Kenya, Sudan, South Africa. 5. CumminS Engine 6. Leateck alternator.
Model No.
STANDBY POWER
PRIME POWER
ENGINE
ALTERNATOR
CONTROLLER
KVA
KW
KVA
KW
OCL-688
688
550
N/A
KTAA19-G6A
LTG354FA1
6110
230/400VAC,50Hz,0.8PF (lag),Three phase four wire
Generator set specifications
Governor Class
ISO8528 G3
Potential Drop
1%
Steady Voltage Regulation
1%
Frequency Drop
Synchronous(0%)
Steady-state Frequency
0.25%
R.R.I.Suppression
BS EN 61000-6-4 / BS EN 61000-6-2
Fuel Consumption Rate ,g/kw.h(L/hr)
207 (125.16)
Starting Battery Capacity ,A/hrhhr
200*2
Total Coolant Capacity ,L
116.5
Fuel Capacity (base tank),L
N/A
Engine Data
Model
KTAA19-G6A
Type
In-line 6 Cylinder,4 Cycle
Displacement ,L
18.9
Compression Ration
13.0:1
Aspiration
Turbo, Air / Air Cooling
Fuel System
PT type Fuel Pump,EFC Electronic Governor
Bore*Stroke(mm)
159*159
Rated Speed ,rpm
1500
Governor Type
Electronic
Starting Voltage
24V ,Negative ground
Battery Charging System
24V 35A
Lubricant Capacity ,L
50
Coolant Capacity, L
116.5
Alternator Data
Protection Class
IP21
Insulation Class
Class H
Temperature Rise in Standard
125 ºC(When Ambient Temp.is 40 ºC)
Excitation Type
Brushless & Self-excited
Waveform Distortion
No load<1.5% Non-Distorting balanced linear load<5%
Telephone Interference(TIF)
<50
Telephone Interference(THF)
<2%
OPTIONAL ACCESSORIES/SPARE PARTS:
-Sound and water proof enclosure -Trailer/Movable power station -Battery charger -Jacket water heater -Oil heater -Diesel oil heater -Automatic transfer switches(ATS) & paralleling system -Extra fuel tank -Fuel water separator
Warranty: 12 months or 1000 running hours from shipment date. If the quality problem arise during the warranty period, and verified the problem is caused by our genset-body instead of external or natural reasons. (Refer to all kinds of natural disaster, shipping, loading, unloading, wrong-operation, etc), we will supply the relevant spare parts free of charge for maintenance; After the warranty period, we can supply the required spare parts for you under cost prices
Our service quality assurance: 1)Before-sale Service: we provide detailed product technical parameters for equipment choosing and system designing 2)Service quality assurance: our sale staffs are all experience and professional, who can provide the most proper system design and optimized equipment for the customers. 3)After sale maintenance service: We create files for end user and provide them follow-up service, regular return visit and permanent maintenance. 4)Spare parts supply: We provide all kinds of spare parts and technical support. 5)Main overhaul or maintenance service: We provide perennial major overhaul and maintenance service
Oripo Established in 1998, Oripo Power Engineering Co., Ltd is professional leading manufacturer, suppliers, exporter and authorized dealers of diesel gensets. With over 20, 000 square meters and a staff nearly 200, the headqauter is loacted in Foshan city, adjacent to Guangzhou which is the trade center of Guandong province. We offering power genset, industrial genset, silent genset, weather proof genset, Cummins genset, Perkins genset, Yuchai genset, Shanghai Dongfeng genset, Deutz genset, Weichai electric genset, China domestic genset, silent diesel generator, portable power generator, trailer diesel generator and electric power generator.
Currently, Oripo cooperated with multinational companies formed a strategic partnership. Import CUMMINS, PERKINS series generator sets, and purchase engine from with Cummins, SDEC, Yuchai, LOVOL, Deutz, alternater with STAMFORD, MARATHON, LEADTECH and other international or domestic famous brand. Establish a long-term friendly cooperation relations with the branded engine and alternator company, authorized to be the OEM partner, In 2009, Oripoe authorized by Cummins, Shanghai Dongfeng and Yuchai to provide OEM service. As professional qualified manufacturer provide OEM genset, spare parts, after sale service, in order to better serve customers and laid a solid foundation.
During the last ten odd years, Oripo has been dedicated to pursuing professional production, thus prevailing in the market with its superior quality, cutting-edge technology and tailor-made services. Moreover, with an endeavor to expand our business operations, we adhere to ethical business practices, transparent business dealings and work to attain the confidence and trust of our clients.
