| Prod Model: |
EM7500 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Engine Model: |
Gff140 Nes |
| Engine Power: |
12.5PS/Pm |
| Generator Output: |
7.0kVA |
| Dimension: |
600X1290X710mm |
| N.W.: |
280kg |
| G.W.: |
283kg |
| Output Type: |
AC Single Phase |
Product Description
| Model | HDG7500 | HDG10000 |
| ENGINE | Type | Horizontal water-cooled 4-stroke diesel engine | Horizontal water-cooled 4-stroke diesel engine |
| Model | GFF140 NES | GFFRD 180N |
| Cylinders | 1 | 1 |
| Bore X stroke (mm) | 98 X98 | 102 X115 |
| Displacement (cc) | 739 | 903 |
| Maximum Output (ps/rpm) | 14/2400 | 18/2400 |
| Reted Output (ps/rpm) | 12.5/2400 | 16.5/2400 |
| Lubricating oil | SAE#40API CF | SAE#40API CF |
| Cooling system | Radiator | Radiator |
| Fuel | Light diesel oil(SAE#2-D) | Light diesel oil(SAE#2-D) |
| Fuel tank capacity (L) | 10 | 10 |
| GENERATOR | Type | Brushless condenser | Brushless condenser |
| Model | HE13M | HE13L |
| Max. Output (KVA) | 7.5 | 10.5 |
| Reted Output (KVA) | 7.0 | 10 |
| Speed (rpm) | 3000/3600 | 3000/3600 |
| Frequency (Hz) | 50/60 | 50/60 |
| Pole | 2 | 2 |
| Power factor | 1 | 1 |
| Phase | 1 Phase 2 Wire | 1 Phase 2 Wire |
| Voltage | 220-240 | 220-240 |
| DIMENSION AND WEIGHT | Width(mm) | 600 | 600 |
| Length(mm) | 1290 | 1290 |
| Height(mm) | 710 | 710 |
| Net weight(Dry) (kg) | 280 | 325 |
ModelHDG7500
TypeHorizontal water-cooled 4-stroke diesel engine
ModelGFF140 NES
Cylinders1
Bore X stroke (mm)98 X98
Displacement (cc)739
Maximum Output (ps/rpm)14/2400
Reted Output (ps/rpm)12.5/2400
Lubricating oilSAE#40API CF
Cooling systemRadiator
FuelLight diesel oil(SAE#2-D)
Fuel tank capacity (L)10
TypeBrushless condenser
ModelHE13M
Max. Output (KVA)7.5
Reted Output (KVA)7.0
Speed (rpm)3000/3600
Frequency (Hz)50/60
Pole2
Power factor1
Phase1 Phase 2 Wire
Voltage220-240
Width(mm)600
Length(mm)1290
Height(mm)710
Net weight(Dry) (kg)280
