| Prod Model: |
wkh-600 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Generator Type: |
AC, 3 Phases |
| Controller Braking System: |
3-Phase Short Circuit by NFB Brake |
| Model: |
Wkh-600 |
| Max Power: |
700W |
| Stop Method: |
Manual & Electromagnetic Brake |
| Blades Material: |
Carbon Fibre Composite |
| Tower Type: |
6m Guy Cable Tower |
| Top Weight: |
18kg |
| Suggested Battery: |
2 PCS 12V120ah |
| Speed Regulation: |
Automatucally Adjust The Windward Angel |
| Number Of Blade: |
Three Blade |
| Rotating Shaft: |
Horizontal |
| Stress Way Of Blade: |
Resistance |
| Phase: |
3 |
Product Description
Specifications
1 factory direct prices
2 ISO CE
3 3 years warranty
4 fast shipping
5 high wind energy utilization
Characteristics
1. Nacelle: Adopting aluminum alloy, light weight and good heat dispersion.
2. Generator: Rotor adopted NdFeB permanent magnet material, and stator using red copper coiling, high temperature resistance, good conductive performance and high efficiency.
3. Blades: Fiberglass-Reinforced plastic surface with polyurethane filled inside, two pieces of reinforced fiberglass rib goes from top to bottom, high construction strength and water proof.
4. Control system: PLC intelligent control, adopting international famous electrical components, humanization design, all of the operation data displays on touch screen interface.
5. Protection system: Dump load and magnetic brake, double protection ensure the security.
6. Metal part surface treatment: Electrophoresis and painting, anti-rust and anti-corrosion.
7. GPRS (option): Remote monitoring and control, easy to detect system's operating situation anytime and anywhere even by mobile.
8. Hydraulic tower (option): Working with hydraulic system to make tower erect and lay down automatically, easy to operate and save the cost for installation and maintenance.
Our Service
1. Reply inquiry in 24 hours.
2. Please kindly inform us which items you are interested & the reasonable price will be provided you upon receipt of your new inquiry ASAP.
3. Answer your question detailed
4. Solved the problem with you during using our products
Payment & Shipping
1. The quoted price is always valid for 15 days due to the fluctuation of raw material cost.
Please feel free to contact us for the catalogue or prices.
2. Please kindly inform us which items you are interested & the best price will be provided you upon receipt of your new inquiry asap.
3. Samples will be offered to you for our future cooperation.
| Model | WKH-600 |
| Rated Power | 600W |
| Max Power | 700w |
| Start-up Wind Speed | 2m/s |
| Rated Wind Speed | 12m/s |
| Survival Wind Speed | 45m/s |
| Output Voltage | DC24V/48v |
Working Wind Speed
| 2.0-25m/s |
| Rotor Diameter | 1.85m |
| Material of Blades | Carbon Fiber Composite |
| Quantity of Blades | 3/5pcs |
| Speed Regulation | Automatically adjust the windward angle |
| Stop Method | Manual & electromagnetic brake |
| Range of Working Temperature | -40°C -60°C |
| Suggested Battery | 2pcs 12V 120AH |
| Top Weight | 18KG |
| Tower Type | Guy cable tower/6m |
|
|
|
|
|
|
|
|
Hefei Wind Wing Energy Technology Co., Ltd. is the earliest one of the R & D wind energy generation equipment in China. Our company develops under the support of Chinese Wind Power Association, depends on Chinese Academy of Sciences Institute of Automation the long-term technical guidance and the close cooperation. We take the "the national initiative energy crisis subject" as our development goal. Now we have a strong R&D group, and researched and developed a profession leading WIND AND SOLAR SUPPLEMENT new energy generating system.
People are paying attention to our products, for the features: Green energy, environmental protection, regenerative and natural energy, etc. Our systems have widely applied in so many fields: City view, communication station, military army, science & education, weather department, fishing vessel, irrigation, oil well, seawater desalination, open country inspection, and so on.
As the first domestic enterprise developing the WIND AND SOLAR SUPPLEMENT new energy, we have passed ISO9001: 2000 quality and management system certification and EU CE certification. Our WIND AND SOLAR SUPPLEMENT new energy range systems are faithful and popular in the domestic and foreign clients, becoming the profession leading enterprise.
We always persist in the enterprise culture of "being a creditable person, live a worth while life", we insist on providing vast customers with the first-class goods, the top-notch technology heart and soul. We heartedly wish to intensively co-operate with old and new customers for greeting together with the challenge WIND AND SOLAR SUPPLEMENT new energy spring arrival!
