| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Type: |
Basic Diesel Generator |
| Installation Method: |
Fixed |
| Stroke: |
Four Stroke |
| Cooling Method: |
Water Cooling |
| Output Type: |
AC Three Phase |
Product Description
ISO&OEM manufacturer 60Hz 1800rpm 200kw Kangmingsi backup generator set (25kva to 1320kva) with Engine Kangmingsi inline 6 and Marathon alternator, CCS BV optional
1) 60hz Genset Feature
Genset | Engine | Alternator |
| Model | Output | Model | Power
(KW) | Cyl. | Fuel Consumption
100% load
(g/kw.h) | Marathon
(Optional) |
Prime
(KW/KVA) | Standby
(KW/KVA) |
| SDC20II | 20/25 | 22/28 | 4B3.9-G2 | 27 | 4 | 228 | GM-20-4 |
| SDC30II | 30/38 | 33/42 | 4BT3.9-G2 | 40 | 4 | 214 | GM-30-4 |
| SDC40II | 40/50 | 44/55 | 4BT3.9-G2 | 40 | 4 | 214 | MP-40-4 |
| SDC50II | 50/62.5 | 55/69 | 4BTA3.9-G2 | 67 | 4 | 216 | MP-50-4 |
| SDC80II | 80/100 | 88/110 | 6BT5.9-G2 | 100 | 6 | 214 | MP-90-4 |
| SDC100II | 100/125 | 110/137.5 | 6BTA5.9-G2 | 120 | 6 | 211 | MP-104-4 |
| SDC120II | 120/150 | 132/165 | 6BTAA5.9-G2 | 132 | 6 | 208 | MP-120-4 |
| SDC160II | 160/200 | 176/220 | 6CTA8.3-G2 | 170 | 6 | 210 | MP-160-4 |
| SDC180II | 180/225 | 198/248 | 6CTAA8.3-G2 | 190 | 6 | 205 | MP-180-4 |
| SDC200II | 200/250 | 220/275 | 6LTAA8.9-G2 | 235 | 6 | 197 | MP-200-4 |
| SDC200II | 200/250 | 220/275 | NT855-GA | 234 | 6 | 201 | MP-200-4 |
| SDC250II | 250/313 | 275/344 | NTA855-G1 | 287 | 6 | 201 | MP-250-4 |
| SDC300II | 300/375 | 330/413 | NTA855-G1B | 313 | 6 | 201 | MP-300-4 |
| SDC320II | 320/400 | 352/440 | NTA855-G3 | 358 | 6 | 201 | MP-320-4 |
| SDC350II | 350/438 | 385/482 | KTA19-G2 | 392 | 6 | 196 | MP-350-4A/S |
| SDC400II | 400/500 | 440/550 | KTA19-G3 | 463 | 6 | 196 | MP-400-4A/S |
| SDC450II | 450/563 | 495/619 | KTA19-G4 | 507 | 6 | 196 | MP-450-4A/S |
| SDC500II | 500/625 | 550/688 | KTAA19-G5 | 533 | 6 | 196 | MP-500-4A/S |
| SDC550II | 550/688 | 605/757 | KTAA19-G6A | 604 | 6 | 196 | MX-560-4 |
| SDC600II | 600/750 | 660/825 | KTA38-G | 679 | 12 | 196 | MX-600-4 |
| SDC750II | 750/938 | 825/1032 | KTA38-G2 | 809 | 12 | 196 | MX-750-4 |
| SDC800II | 800/1000 | 880/1100 | KTA38-G2A | 915 | 12 | 196 | MX-850-4 |
| SDC900II | 900/1125 | 990/1238 | KTA38-G4 | 1007 | 12 | 196 | MX-900-4 |
| SDC1000II | 1000/1250 | 1100/1375 | KTA38-G9 | 1109 | 12 | 196 | MX-1030-4 |
| SDC1100II | 1100/1375 | 1210/1513 | KTA50-G3 | 1220 | 16 | 196 | MX-1240-4 |
| SDC1200II | 1200/1500 | 1320/1650 | KTA50-G9 | 1384 | 16 | 196 | MX-1240-4 |
Specifications:
1) Output range: 20kW (25kVA) up to 1200kW (1320kVA),
2) Engine: Kangmingsi
3) Alternator: Stamford, Marathon, Siemens, Sanbo
4) 8hrs operation base tank optional
5) Auto start /stop control panel
6) Frequency at stable state: <0.5%
7) Voltage deviation at stable state: ≤±1%
8) Voltage modulation: ≤0.3%
9) Insulation class H; Protection class IP23
2)Control panel Feature
Brand: Smartgen
Feature:
1. Microprocessor control module, with high stability and credibility
2. Monitoring and measuring operational parameters of the generator set
3. Indicating operation status, fault conditions, all parameters and alarms
4. Multiple protections, multiple parameters display like pressure, temp. etc
5. Manual and automatic work mode selectable
6. Language optional of Chinese, English, Russian etc.
7. LED display, touch control
8. Real time clock display and log entries
Function optional: AMF, ATS, Paralleling, Remote control
Parameter:
Generator Volts, Amps, Frequency, active power, apparent power, power factor, Engine Oil Pressure, battery volt, Engine speed, engine temperature, Engine Hours Run, fuel level.
Protection:
1.Low Oil Pressure 2.High voltage and low voltage 3. Volt adjuster and frequency adjuster
4.Overspeed 5. Emergency stop 6.Fail to start 7. High Engine Temperature
Sudong Power, Your reliable partner for Power generator!
Any problem, Be free to contact me at Skype justinguo2006, Taizhou, China
Sudong Power is a specialist company in design and manufacture of generator sets. For over 11 years' of development, Sudong power has earned the reputation in the market to supply power solutions for various applications with a broad range in power capacities.
With a strong team of specialist engineers, Sudong power provides standard power products and tailored power solutions to the most challenging and complex power requirements of even the most exacting customers. All our products benefit from the practical experience of our genset development engineers and close cooperation with our world class suppliers. Sudong gensets are widely used in ship building, harbor equipments, finance systems, transportations, factories, militaries, hospitals, commerical building, airports and railway power cars, maritime projects etc. And our marine genset is approval by the relative class society such as CCS, BV, ABS, DNV, GL, RINA, RS etc. Products and services quality have received highly recognitions of domestic and overseas customers.
Our goal is o sustain at the forefront of domestic and global market for power solutions in an uograding power range in terms of perofrmance, quality and services. SUDONG POWER is trading forward to this goal with steady steps.
