| Prod Model: |
FD6-6kw |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Rated Power: |
6kw |
| Blades Rotor Diameter: |
6m |
| Rated Wind Speed: |
12m/S |
| Working System: |
Grid Tie, off Grid, Wind Solar Hybrid |
| Max Output Power: |
7kw |
| Working Voltage: |
96V 120V 240V 380V |
| Wind Turbine Type: |
Horizontal Axis, Directly Drive, C.W |
| Tower Height: |
8m-15m |
| Generator Type: |
3 Phrase AC Pmg |
| Number Of Blade: |
Three Blade |
| Rotating Shaft: |
Horizontal |
| Stress Way Of Blade: |
Lift Force |
| Phase: |
3 Phrase |
| Certification: |
IEC |
Product Description
| Model: | FD6-6000w |
| Rotor Diameter: | 6m |
| Number of Blades: | 3pcs |
| Material of Blades: | Fibre glass expoxy |
| Cut-in wind speed: | 3m/s |
| Working wind speed: | 4-30m/s |
| Survival wind speed: | 50m/s |
| Rated wind speed: | 12m/s |
| Rated rotate speed: | 250r/min |
| Rated output power: | 6kw |
| Max output power: | 7.5kw |
| Type of generator: | Permanent-magnet 3 phrase AC |
| Speed regulation method: | Yaw |
| Stop method: | Brake by hand drag |
| Working voltage: | 120v, matched with 12m storage battery 10 pcs. |
| Tower height: | 12m |
| Wind turbine main body weight: | 450kg |
| Measurement(CBM): | 1.8CBM (wind turbine main body) |
| Life span: | 15-20 years; |
Fixed pitch FD6-6kw wind turbine
on grid system/off grid system/wind solar hybrid system
Tower: tilting up tower, guy wire tower, stand alone tower (optional)
User can take whole system from us, also can take any part of the system from us.
Qingdao Henryd Wind power Equipment Co., Ltd. is specialized small wind turbine generator manufacture in China. We own over 10 years practical experience in technical research, development and application of wind turbines. Also we have a strong r & d team to give our wind turbine tech supports. Our sales dept with many years experience in trading area will give you more supports.
We provide:
1)300w-30kw horizontal wind generator off-grid working system
1kw, 2kw,2.5kw 3kw, 5kw, 10kw, 20kw 25kw 30kw on-grid working system
2.)Vertical axis wind turbine 1kw 2kw,3kw 5kw
5-7 pcs stallout FRB blades.
3.) Variable pitch wind turbine 2kw 3kw 5kw 10kw 20kw 30kw 50kw 60kw
4.)2.2m-24m(diameter) frb, horizontal axis, 3 PCS aerofoil blades, past wind tunnel test, high efficiency.
5. )guy wire tower, independance tower, tilting up tower, hydraulic tower
--factory direct sales--
Good price and higher quality, provide technical support more professional.
