Copy Stamford Brushless Alternator 6kw~160kw

Name: Copy Stamford Brushless Alternator 6kw~160kw
Brand: aboutgenerator.com
SKU: 778646995
Availability: InStock
Rating: 4.3 (75 reviews)

Price:	US $ 120-1500/Piece
Trade Terms:	FOB,CFR,CIF
Min Order:	10/Piece
Pay Type:	L/C,T/T,Paypal,Western Union

Contact Supplier

FUAN BOYUAN POWER MACHINERY CO., LTD.

Showroom Product Company Profile

Prod Model:	164, 184, 224, 264
Markets:	South America,Southeast Asia,Africa,Mid East,Eastern Asia,Western Europe
Wire:	Copper or Aluminum
Bearing:	Double Bearing or Single Bearing
Cooling Method:	Fan Cooling
Protection Class:	IP23
Insulation Class:	H
Constant Working Type:	S1
Brand:	Xby or OEM
Color:	as Customers Requirements

Product Description

BY series brushless alternator, electric generator
FEATURE:
1-Can be coupled with any permanent magnetic generators, providing invariable excitation on all occasions.
2-Comply with the most common standard in terms of GB755, IEC60034, BS5000, VDE0530, CSAC22.2-100.
3-Single or double bearings are available, options for all kinds of adaptors and disc plates.
4-12-end reconnectable winding terminals to get different voltages.
5-Standard H insulation class.
6-Covenient installation and maintenance for lead-end rotated diodes and adaptor connected bolts.
7-Standard sealed maintenance-free bearingsj.
8-Standard IP23 protection, optional severe enviroment protection,

TECHNICAL PERFORMANCCE:
1-Adjusting rate of stable voltage ±0.5%
2-Adjusting rate of instant voltage: ≥-15% ~ ≤+20%
3-Adjusting range of voltage: ≥±25%
4-Insulation class: H
5-Constant working type: s1
6-Protection class: IP23

TECHNICAL DATE:

Technical Date for BY 164 series
	Three phase H class temperature(125ºC)								Single phase H class temperature(125ºC)
Voltage	50HZ, 1500RPM				60HZ, 1800RPM				50HZ, 1500RPM			60HZ, 1800RPM
Star series connection	380	400	415	440	416	440	460	480	220	230	240	220	230	240
Star PARALLEL CONNECTION	190	200	208	220	208	220	230	240	110	115	120	110	115	120
Triangle series connection	220	230	240	254	240	254	-	-	-	-	-	-	-	-
BY 164A rated capacity(KVA)	8.1	8.1	8.1	8.1	9.6	10.2	10.2	10.2	5.4	5.4	5.4	6.4	6.4	6.4
Rated output(KW)	6.5	6.5	6.5	6.5	7.7	8.2	8.2	8.2	4.3	4.3	4.3	5.1	5.1	5.1
Efficiency	75.6	76.2	76.6	77.1	75.8	76.3	76.9	774	69.6	69.6	70	69.5	70.1	70.6
Input(kw)	8.6	8.5	8.5	8.4	10.1	10.7	10.6	10.5	6.2	6.2	6.2	7.4	7.3	7.3
BY 164B rated capacity(KVA)	11	11	11	11	13	13.8	13.8	13.8	7.4	7.4	7.4	8.8	8.8	8.8
Rated output(KW)	8.8	8.8	8.8	8.8	10.4	11	11	11	5.9	5.9	5.9	7	7	7
Efficiency	78.8	79.4	79.8	80.2	79	79.4	80	80.5	73.5	73.8	73.9	73.3	73.9	74.4
Input(kw)	11.2	11.1	11	11	13.2	13.9	13.8	13.7	8.1	8	8	9.6	9.5	9.5
BY 164C rated capacity(KVA)	13.5	13.5	13.5	13.5	16	16.9	16.9	16.9	9	9	9	10.8	10.8	10.8
Rated output(KW)	10.8	10.8	10.8	10.89	12.8	13.5	13.5	13.5	7.2	7.2	7.2	8.6	8.6	8.6
Efficiency	80	80.7	81	81.5	80.3	80.7	81.3	81.7	75.2	75.5	75.7	75	75.6	76
Input(kw)	13.5	13.4	13.3	13.3	15.9	16.7	16.6	16.5	9.6	9.5	9.5	11.5	11.4	11.4
BY 164D rated capacity(KVA)	16	16	16	16	18.9	20	20	20	10.7	1.7	10.7	13.5	13.5	13.5
Rated output(KW)	12.8	12.8	12.8	12.8	15.1	16	16	16	8.6	8.6	8.6	10.8	10.8	10.8
Efficiency	81	81.6	81.9	82.4	81.2	81.7	82.2	82.7	76.5	76.7	76.9	76.4	76.9	77.4
Input(kw)	15.8	15.7	15.6	15.5	18.6	19.6	19.5	19.4	11.2	11.1	11.1	13.1	13	12.9

Technical Date for BY 184 series
	Three phase H class temperature(125ºC)									Single phase H class temperature(125ºC)
Voltage	50HZ, 1500RPM				60HZ, 1800RPM					50HZ, 1500RPM			60HZ, 1800RPM
Star series connection	380	400	415	440	416	440	460	480	600	220	230	240	220	230	240
Star PARALLEL CONNECTION	190	200	208	220	208	220	230	240	300	110	115	120	110	115	120
Triangle series connection	220	230	240	254	240	254	266	277	346	-	-	-	-	-	-
BY 184E rated capacity(KVA)	22.5	22.5	22.5	22.5	27.5	28.8	28.8	30	30	15	15	15	18.4	18.4	18.4
Rated output(KW)	18	18	18	18	22	23	23	24	24	12	12	12	14.7	14.7	14.7
Efficiency	84.3	84.9	85.3	85.8	83.8	84.3	84.9	85.2	85.6	81.3	81.7	81.9	79.9	80.6	81.1
Input(kw)	21.4	21.2	21.1	21	26.2	27.1	27.1	28.2	28	14.8	14.7	14.6	18.4	18.3	18.1
BY 184F rated capacity(KVA)	27.5	27.5	27.5	27.5	32.5	34.4	34.4	35	35	18.5	18.5	18.4	21.9	21.9	21.9
Rated output(KW)	22	22	22	22	26	27.5	27.5	28	28	14.8	14.8	14.8	17.5	17.5	17.5
Efficiency	85.7	86.2	86.5	87	85.5	85.9	86.4	86.7	87	82.7	83	83.3	81.9	81.9	82.8
Input(kw)	25.7	25.5	25.4	25.3	30.4	32	31.9	32.3	32.2	17.9	17.8	17.8	21.4	21.4	21.2
BY 184G rated capacity(KVA)	31.3	31.3	31.3	31.3	35	37.5	37.5	37.5	37.5	21	21	21	25	25	25
Rated output(KW)	25	25	25	25	28	30	30	30	30	16.8	16.8	16.8	20	20	20
Efficiency	86.6	87	87.3	87.6	86.7	87	87.3	87.6	87.8	83.7	83.9	83.9	83	83	83.8
Input(kw)	28.9	28.8	28.7	28.6	32.3	34.5	34.4	34.2	34.2	20.1	20	20	24.1	24.1	23.9
BY 184H rated capacity(KVA)	37.5	37.5	37.5	37.5	44.3	46.9	46.9	46.9	46.8	25	25	25	31.3	31.3	31.3
Rated output(KW)	30	30	30	30	35.4	37.5	37.5	37.5	37.4	20	20	20	25	25	25
Efficiency	86.2	86.6	86.9	87.2	85.4	85.3	85.6	85.9	85.9	82.9	82.9	82.9	82.8	82.8	82.8
Input(kw)	34.8	34.7	34.6	34.5	41.5	44	43.9	43.7	43.7	24.2	24.2	24.2	30.2	30.2	30.2
BY 184J rated capacity(KVA)	40	42.5	10	40	47.3	50	50	50	55	28	28	28	35	35	35
Rated output(KW)	32	34	32	32	37.8	40	40	40	44	22.4	22.4	22.4	28	28	28
Efficiency	87.6	86.6	87.1	87.5	85.9	85.8	86.1	86.4	86.4	83	83	83	82.9	83	83
Input(kw)	37	39.3	36.7	36.6	44	46.7	46.5	46.3	46.3	27	27	27	33.8	33.8	33.8

Technical Date for BY 224 series
	Generator Land									Generator Marine
	50HZ 1500RPM				60HZ 1800RPM					50HZ 1500RPM				60HZ 1800RPM
Voltage	H Rank(125K)				H Rank(125K)					H Rank(125K)				H Rank(125K)
Star series connection	380	400	415	440	416	440	450	460	480	380	400	415	440	416	400	450	460	480
Star PARALLEL CONNECTION	190	200	208	220	208	220	225	230	240	190	200	208	220	208	220	225	230	240
Triangle series connection	220	230	240	254	240	254	260	266	277	220	230	240	254	240	254	260	266	277
BY 224C rated capacity(KVA)	42.5	42.5	42.5	40	50	52.5	52.5	52.5	55	37.5	37.5	37.5	35	43.8	43.8	43.8	43.8	43.8
Rated output(KW)	34	34	34	32	40	42	42	42	44	30	30	30	28	35	35	35	35	35
Efficiency	86.5	87.1	87.4	88.2	86.8	87.2	87.5	87.7	87.9	87.1	87.6	87.8	88.5	87.6	88	88.2	88.4	88.6
Input(kw)	39.3	39	38.9	36.3	46.1	48.2	48	47.9	50.1	34.4	34.2	34.2	31.6	40	39.8	39.7	39.6	39.5
BY 224D rated capacity(KVA)	50	50	50	48	60	625	62.5	62.5	65	43.8	43.8	43.8	40	50	52.5	56.3	56.3	56.3
Rated output(KW)	40	40	40	38.4	48	50	50	50	52	35	35	35	32	40	42	45	45	45
Efficiency	87.8	88.2	88.5	89	87.8	88.2	88.4	88.6	88.8	88.2	88.6	88.9	89.2	88.6	88.8	88.9	89.1	89.3
Input(kw)	45.6	45.4	45.2	43.1	54.7	56.7	56.6	56.4	58.6	39.7	39.5	39.4	35.9	45.1	47.3	50.6	50.5	50.4
BY 224E rated capacity(KVA)	60	60	60	58	67.5	70	71.3	72.5	75	50	50	50	50	62.5	62.5	62.5	62.5	62.5
Rated output(KW)	48	48	48	46.4	54	56	57	58	60	40	40	40	40	50	50	50	50	50
Efficiency	88.1	88.6	88.9	89.5	88.5	88.9	89.1	89.2	89.4	88.9	89.2	89.5	89.8	88.9	89.3	89.6	89.8	89.9
Input(kw)	54.5	54.2	54	51.8	61	63	64	65	67.1	45	44.8	44.7	44.5	56.2	56	55.8	55.7	55.6
BY 224F rated capacity(KVA)	72.5	72.5	72.5	70	83.8	87.5	87.5	87.5	93.8	62.5	62.5	62.5	62.5	75	75	75	75	81.3
Rated output(KW)	58	58	58	56	67	70	70	70	75	50	50	50	50	60	60	60	60	65
Efficiency	89.6	90	90.2	90.6	89.9	90.2	90.4	90.5	90.5	90	90.23	90.6	90.7	90.2	90.89	90.9	91	91
Input(kw)	64.7	64.4	64.3	61.8	74.6	77.6	77.5	77.3	82.9	55.6	55.4	55.2	55.1	66.5	66.1	66	65.9	71.4
BY 224G rated capacity(KVA)	85	85	85	79	93.8	97.5	98.8	100	104	75	75	75	65	87.5	87.5	87.5	93.8	93.8
Rated output(KW)	68	68	68	63.2	75	78	79	80	83	60	60	60	52	70	70	70	75	75
Efficiency	89.9	90.2	90.4	90.8	90.4	90.6	90.7	90.8	91	90.4	90.6	90.8	91.1	90.6	91	91	91	91.2
Input(kw)	75.6	75.4	75.2	69.6	83	86.1	87.1	88.1	91.3	66.4	66.2	66.1	57.1	77.3	76.9	76.9	82.4	82.2

Technical Date for BY 224 series
	Generator Land									Generator Marine
	50HZ 1500RPM				60HZ 1800RPM					50HZ 1500RPM				60HZ 1800RPM
Voltage	H Rank(125K)				H Rank(125K)					H Rank(125K)				H Rank(125K)
Star series connection	380	400	415	440	416	440	450	460	480	380	400	415	440	416	400	450	460	480
Star PARALLEL CONNECTION	190	200	208	220	208	220	225	230	240	190	200	208	220	208	220	225	230	240
Triangle series connection	220	230	240	254	240	254	260	266	277	220	230	240	254	240	254	260	266	277
BY 274C rated capacity(KVA)	100	100	100	92.5	113	118	118	118	125	81.3	81.3	81.3	75	93.8	106	106	106	113
Rated output(KW)	80	80	80	74	90	94	94	94	100	65	65	65	60	75	85	85	85	90
Efficiency	89.8	90.4	90.7	91.4	90	90.4	90.7	90.9	91	90.8	91.1	91.3	91.8	90.8	89.9	89.9	89.9	91.3
Input(kw)	98.1	88.5	88.2	81	100	104	104	103	110	71.6	71.4	71.2	65.4	82.6	94.5	94.5	94.5	98.6
BY 274D rated capacity(KVA)	114	114	114	109	131	138	138	138	146	100	100	100	87.5	119	119	125	125	125
Rated output(KW)	91	91	91	87	105	110	110	110	117	80	80	80	70	95	95	100	100	100
Efficiency	90.3	90.8	91	91.6	90.4	90.7	90.9	91.1	91.2	90.7	91.1	91.4	92	90.8	91.2	91.3	91.4	91.7
Input(kw)	10.1	100	100	95.2	116	121	121	121	128	88.2	87.8	87.5	76.1	105	104	110	109	109
BY 274E rated capacity(KVA)	140	140	140	130	160	168	168	168	179	125	125	125	113	138	138	138	144	144
Rated output(KW)	112	112	112	104	128	134	134	134	143	100	100	100	90	110	110	110	115	115
Efficiency	91.3	91.7	92	92.5	91.4	91.7	91.9	92	92.1	91.7	92.1	92.3	92.7	91.9	92.2	92.4	92.6	92.7
Input(kw)	123	122	122	112	140	146	146	146	155	109	109	108	97.1	120	119	119	124	124
BY 274F rated capacity(KVA)	160	160	160	150	181	190	190	190	206	144	144	144	125	163	163	169	169	169
Rated output(KW)	128	128	128	120	145	152	152	152	165	115	115	115	100	130	130	135	135	135
Efficiency	91.9	92.3	92.5	93	92	92.3	92.5	92.6	92.6	92.2	92.6	92.8	93	92.2	92.7	92.7	92.9	93.1
Input(kw)	139	139	138	129	158	165	164	164	178	125	124	124	108	141	140	146	145	145
BY 274G rated capacity(KVA)	175	175	175	171	200	213	213	213	225	156	156	156	150	188	188	188	188	200
Rated output(KW)	140	140	140	137	160	170	170	170	180	125	125	125	120	150	150	150	150	160
Efficiency	92.2	92.5	92.7	93	92.2	92.4	92.6	92.7	92.8	92.5	92.8	93	93.2	92.3	92.7	92.9	93	93
Input(kw)	152	151	151	147	174	184	184	183	194	135	135	134	129	163	162	162	161	172
BY 274h rated capacity(KVA)	200	200	200	190	238	245	245	245	255	175	175	175	163	219	225	225	225	231
Rated output(KW)	160	160	160	152	190	196	196	196	204	140	140	140	130	175	180	180	180	185
Efficiency	93	93.3	95.3	93.8	92.9	93.2	93.4	93.5	93.6	93.3	93.6	93.7	93.9	93.1	93.2	93.4	93.5	93.6
Input(kw)	172	171	171	162	205	210	210	210	218	150	150	149	138	188	193	193	193	198

Remark:
All land rate data: 40ºC(Attitude not exceed 1000m)
All listed voltages are obtained from a wide range of individual winding.I.E.from recombination from 12 outlet terminal(3 phase) and 4 outlet terminal(single phase)
Other optional voltage range according to customer demand.

Fuan BoYuan Power Machinery Co., Ltd ( abbreviation: BY Power), Located in Fu'an City, Fujian Province, which is famous manufacturing industrial zone in Southeast China.

BY Power is specialized in manufacturing Diesel Generating Set, brushless alternator, AC synchronous alternator, and supplying various power products, like engine parts, controllers, ATS etc.

BY Power manufactures OEM generator powered by Cummins, Deutz, Volvo, MTU, Doosan engines and Stamford, Leroy Somer, Mecc Alte alternators. BY Power Generator set ranges from 7KW to 1200KW, 50Hz or 60Hz frequency, with open type, silent type, trailer type and containerized type, etc. All products are manufactured in accordance with the ISO9001 production standard to assure them of best quality produced and accepted for export to the international market. The products are mainly exported to Middle East, Africa & Southeast Asia countries and regions.

All staffs of produce and inspection team works for the industry more than 10years. They are professional and passionate for their job.

As a brand new profession manufacturer, our advantage is professional work team, strict inspection controll system and good service.

Our Advantages:

1. Solve your technical problems in 24 hours and provide international warranty service for engines

2. Design the appearance form according to customers' request

3. Polyester varnish for appearance protecting for shining and raining

4. Two hours testing before out factory

Warranty policy

The goods are under warranty against defects in material and workmanship for a period of 12 months or 1000 hours, whichever come first from the date of delivery to the end user except the damageable spare parts of genset caused by incorrect man-made operation, and that the aforementioned warranty for the same taken is back up by the engine and alternator suppliers.
