| Prod Model: |
CCFJ*J |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Engine Brand: |
Cummins |
| Prime Power: |
40kw-800kw |
| Frequency: |
50Hz 1500rmp or 60Hz 1800rmp |
| Cooling Method: |
Water Cooling |
| Stroke: |
Four Stroke |
| Installation Method: |
Fixed |
| Type: |
Micro-Computer Control Automatic Diesel Generator |
Product Description
1. CCS / BV approved. EIAPP certificate, ISO, CE approved.
2. 20years experience for marine and industrial generator
3. 1year or 1000hours international garantee
Coupled with Cummins diesel engine and Marathon
Alternator
24V DC start motor
Brushless, Self-excited, IP23, insulation class H alternator
Genset Main Technical Data
3-pH, 50Hz@1500RPM, 400/230V (Also Can Be Made According To Customers' Special Requirements)
Control system
Engine start/stop
Engine coolant temperature
Oil pressure and temperature
Tachometer
Coolant temperature alarm
Oil pressure alarm
Battery charging indicator
Generator to be protection from overload and overheat
|
Model |
Output |
Cummins |
Fuel |
Dimension |
|
Diesel engine |
Consumption |
(L× W× H) |
|
KVA |
KW |
|
(g/kw. h) |
(mm× mm× mm) |
|
CCFJ40J |
50 |
40 |
4BTA3.9-GM47 |
213 |
1500X750X1320 |
|
CCFJ50J |
63 |
50 |
6BT5.9-GM83 |
212 |
1850X820X1350 |
|
CCFJ64J |
80 |
64 |
6BT5.9-GM83 |
212 |
1850x820x1350 |
|
CCFJ70J |
88 |
70 |
6BT5.9-GM83 |
212 |
1850X820X1350 |
|
CCFJ80J |
100 |
80 |
6BTA5.9-GM100 |
212 |
1900X850X1400 |
|
CCFJ90J |
113 |
90 |
6CT8.3-GM115 |
212 |
1900X850X1400 |
|
CCFJ100J |
125 |
100 |
6CT8.3-GM115 |
212 |
2100X800X1360 |
|
CCFJ120J |
150 |
120 |
6CTA8.3-GM155 |
212 |
2100X800X1360 |
|
CCFJ150J |
188 |
150 |
6LTAA8.9-GM200 |
198 |
2400X900X1400 |
|
CCFJ150J |
188 |
150 |
NT855-DM |
203 |
2550X980X2250 |
|
CCFJ180J |
225 |
180 |
NT855-DM |
203 |
2550X980X2250 |
|
CCFJ200J |
250 |
200 |
NTA855-DM |
208 |
2580X980X2290 |
|
CCFJ250J |
313 |
250 |
NTA855-DM |
205 |
2620x980x2290 |
|
CCFJ270J |
338 |
270 |
NTA855-DM |
205 |
2650X1000X2300 |
|
CCFJ280J |
350 |
280 |
NTA855-DM |
205 |
2650X1000X2300 |
|
CCFJ300J |
375 |
300 |
KTA19-DM |
209 |
3100X950X2080 |
|
CCFJ350J |
438 |
350 |
KTA19-DM |
204 |
3150X1000X2150 |
|
CCFJ400J |
500 |
400 |
KTA19-DM |
204 |
3150X1000X2150 |
|
CCFJ500J |
625 |
500 |
KT38-DM |
214 |
4100X1650X2200 |
|
CCFJ600J |
750 |
600 |
KTA38-DM |
214 |
4100X1650X2200 |
|
CCFJ720J |
900 |
720 |
KTA38-DM |
205 |
4150X1650X2200 |
|
CCFJ800J |
1000 |
800 |
KTA38-DM |
199 |
4200X1700X2350 |
Taizhou Fengde Mechanical & Electrical Manufacturing Co., Ltd has been established for over 18 years, reformed from a national military industrial enterprise. Fengde owns a experienced and professional staff group, as well as senior engineer, technician and salesman; Now is known as a leading manufacturer in supplying of diesel generator (for both industrial and marine use) and Vessel Switchboard in China.
We have been authorized by CE and the Quality management system of ISO9001: 2008, and have been appointed as a vessel inspection unit by the China Classification Society CCS. Our marine generator and vessel Switchboard can be approved by CCS, ABS, BV, DNV, GL, LR, GL, RS etc. With steady quality, quick and professional service, Fengde gains general recognition from users domestic and abroad.
We are sincerely looking forward to establishing the business relationship with you for our mutual benefit. We are at your service!
