Cummins/Perkins/Volvo/Mitsubishi Silent Diesel Engine Power Electric Generator

Markets:	South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia
Engine Brand:	Cummins/Perkins
Color:	Green/Red/Blue/Grey/Yellow etc
Controller:	Deepsea/Harsen
ATS:	Optional
Soundproof:	Optional
Type:	Basic Diesel Generator
Installation Method:	Fixed
Stroke:	Four Stroke
Cooling Method:	Water Cooling
Output Type:	AC Three Phase

Product Description

At SUTER POWER, we maintain a full stock of dependable, world-class Silent diesel generators from 8kW to 2000kW including but not limited to Cummins, Perkins, Volvo, Mitsubishi, Yamaha, MAN, Stamford, Leroy Somer and Mecc alte etc. For further information about the line of Cummins generators that we keep in stock, you can send email See for yourself how Cummins generators can aid your organization.

Features of diesel generators:

1. International Warranty Service

2. Short delivery time, as we always have engine & alternator in stock

3. With ISO9001 & CE certification

4. Spare parts are easy to get from worldwide market with much cheaper price

5. Coupled with Mecc alternator or other alternator(Stamford, Leory-Somer, Marthon as optional)

6. Perfect after-service network

7. Both 50Hz and 60Hz

8. Rigorous test including 50% load, 75% load, 100% load and 110% load

CUMMINS GENERATOR SET (50Hz 1500rpm 230/400V 3P4W)
Model	Standby Power		Prime Power		Diesel Engine	Dimension (L*W*H)(mm)	Weight (kg)
	KVA	KW	KVA	KW	Cummins
C28GF-50	28	22	25	20	4B3.9-G1	1820*760*1280	876
C40GF-50	41	33	38	30	4BT3.9-G1	1820*760*1400	893
C65GF-50	65	52	60	48	4BTA3.9-G2	2000*760*1450	930
C100GF-50	100	82	92	75	6BT5.9-G1	2230*830*1490	1450
C110GF-50	110	88	100	80	6BT5.9-G2	2230*830*1490	1450
C125GF-50	125	100	115	92	6BTA5.9-G2	2300*850*1520	1500
C142GF-50	142	114	130	104	6BTAA5.9-G2	2300*850*1520	1500
C175GF-50	175	140	160	128	6CTA8.3-G2	2480*880*1650	1850
C200GF-50	200	160	181	145	6CTA8.3-G2	2480*880*1650	1850
C225GF-50	220	180	200	160	6CTAA8.3-G2	2540*980*1650	2050
C275GF-50	275	220	250	200	NT855-GA	2540*980*1670	2200
C300GF-50	300	240	275	220	NTA855-G1A	3300*1150*1700	2600
C360GF-50	360	280	320	256	NTA855-G1B	3300*1150*1700	2800
C400GF-50	400	320	360	280	NTA855-G2A	3300*1150*1700	2900
C450GF-50	450	360	400	320	NTAA855-G7A	3300*1150*1700	3000
C500GF-50	500	400	450	360	KTA19-G3	3400*1258*2050	3400
C550GF-50	550	440	500	400	KTAA19-G3A	3400*1258*2050	4600
C650GF-50	650	520	NA		KTA19-G8	3650*1638*2050	4600
C688GF-50	688	550	NA		KTAA19-G6A	3650*1638*2050	5000
C825GF-50	825	660	750	600	KTA38-G2	4500*2060*2430	6850
C880GF-50	880	703	800	640	KTA38-G2B	4500*2060*2430	8000
C1000GF-50	1000	800	910	728	KTA38-G2A	4500*2060*2430	8000
C1100GF-50	1100	880	1000	800	KTA38-G5	4800*2060*2430	8600
C1250GF-50	1250	1000	NA		KTA38-G9	5000*2200*2400	9000
C1375GF-50	1375	1100	1250	1000	KTA50-G3	5000*2200*2500	10000
C1600GF-50	1600	1320	1500	1200	KTA50-GS8	5811*1765*2241	10626

Standard configuration diesel generators:

1) Diesel engine

2) Mecc alternator(Stamford, Leory-Somer & China alternator for option)

3) Deepsea DSE7320 or ComAq control panel with AMF fuction, ATS for option

4) Chint circuit breaker

5) 8 Working Hours Base Fuel Tank(for the genset≤650kVA prime, only Base Frame for other models)

6) Anti-Vibration Mounted System

7) Battery and battery charger

8) Industrial silencer and flexible exhaust hose

PERKINS GENERATOR (50Hz 1500rpm 230/400V 3P4W)
Model	Standby Power		Prime Power		Perkins Engine	Dimension
	KVA	KW	KVA	KW	Model	L*W*H mm
P10GF	10	8	9	7.2	403D-11G	1100*550*890
P14GF	14	11.2	13	10.5	403D-15G	1200*600*920
P22GF	22	17.6	20	16	404D-22G	1350*600*950
P30GF	30	24	27	22	404D-22TG	1400*650*1100
P33GF	33	26.4	30	24	1103A-33G	1500*730*1150
P50GF	50	40	45	36	1103A-33TG1	1600*730*1200
P66GF	66	53	60	48	1103A-33TG2	1750*750*1250
P72GF	72	57.2	65	52	1104A-44TG1	1950*750*1250
P88GF	88	70	80	64	1104A-44TG2	1950*750*1250
P100GF	100	80	90	72	1006TG1A	2350*860*1550
P110GF	110	88	100	80	1006TG2A	2350*860*1550
P130GF	130	118	135	108	1106A-70TAG1	2400*850*1400
P165GF	165	150	132	120	1106A-70TAG2	2400*850*1400
P200GF	200	160	180	144	1106A-70TAG3	2400*850*1400
P220GF	220	176	200	160	1106A-70TAG4	2400*850*1400
P250GF	250	200	225	180	1306C-E87TAG4	2600*1050*1600
P275GF	275	220	250	200	1306C-E87TAG6	2600*1050*1600
P385GF	385	308	350	280	2206A-E13TAG2	3150*1200*2000
P450GF	450	360	400	320	2206A-E13TAG3	3150*1200*2000
P500GF	500	400	455	364	2506A-E15TAG1	3500*1200*2050
P550GF	550	440	500	400	2506A-E15TAG2	3500*1200*2050
P660GF	660	528	600	480	2806A-E18TAG1A	3500*1300*2100
P715GF	715	572	650	520	2806A-E18TAG2	3500*1300*2100
P825GF	825	660	750	600	4006-23TAG2A	4100*1750*2170
P880GF	880	700	800	640	4006-23TAG3A	4100*1750*2170
P990GF	990	792	900	720	4008TAG1A	4700*2100*2250
P1100GF	1100	880	1000	800	4008TAG2A	4700*2100*2250
P1375GF	1375	1100	1250	1000	4012-46TWG2A	5000*1800*2500
P1485GF	1485	1188	1350	1080	4012-46TWG3A	5000*2100*2550
P1650GF	1650	1320	1500	1200	4012-46TAG2A	5000*2200*2550
P1880GF	1880	1504	1710	1368	4012-46TAG3A	5000*2200*2550
P2035GF	2035	1628	1850	1480	4016TAG1A	6850*2250*2850
P2200GF	2200	1760	2000	1600	4016TAG2A	6850*2250*2850
P2500GF	2500	2000	2250	1800	4016-61TRG3A	6850*2250*2850

WHY CHOOSE US
Reason 1:
Reliable Manufacturer:
As a specialized Cummins Silent diesel generator manufacturer, its high quality diesel generators have been working well in many fields including railways, oil fields, Schools, hospitals, industries, tall buildings, sea ports and military bases etc.Meanwhile we attach importance to environment protection persistently, and also is one of the few companies which strictly follow ISO14001 Environmental Management System in diesel generators manufacturing industry.Nowadays, with great enthusiasm and persistence efforts, all of us are working toward the goal of being one leading enterprise in the international lines
Reason 2:
High quality:
As a specialized diesel generator manufacturer, we have a quality control and inspection system to monitor the whole process from raw materials to delivery, only raw materials that passed our sophisticated tests can be put into production.Before products departure, each diesel generator must be tested with no load, with load, overload.Our quality system is even stricter than both domestic and abroad standards:GB/T2820, GB1105, YD/T502, ISO8525-3, ISO3046, ISO8525.
Reason 3:
Low cost:
As a specialized diesel generator manufacturer, we have good long-term relationship with our reliable Engine & Alternator partner.Meanwhile, most parts of diesel generator are manufactured by ourselves, we design and manufacture control system, soundproof canopy, trailer etc according to our clients' needs.
Reason 4:
After-sell service:
1.We are available for a 24-hour Tel or Email service, you can leave us a message whenever you want.
2.We provide one-year or 1000 hours running Guarantee for all the products we supplied.
3.We would like to send our technicians abroad for installing the generator sets if required.
Adhering to the motto of "24hrs Power Supply", we will always stay with your needs.
