| Price: | Negotiable/Piece |
|---|---|
| Trade Terms: | FOB,CFR,CIF |
| Min Order: | 1/Piece |
| Pay Type: | L/C,T/T,D/P,Western Union |
| Prod Model: | Dual fuel |
|---|---|
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Gas Source: | Natural Gas |
1.12 years manufacture experience
2. Widely used in SINOPEC and CNPC
3. Isuzu, Steyr, Cummins etc Engine with Marathon/Stamford Generator
4. Certificate: ISO, CE
|
Specifitions |
||
|
Genset model |
HL |
|
|
Type |
open/sound proof/weather proof |
|
|
Genset output power range |
10kw-1000kw |
|
|
Rated voltage |
220/380V,230/400V,240/415V,120/240V |
|
|
Frequency |
50/60HZ |
|
|
Power factor |
0.8 |
|
|
Rated speed |
1500/1800rpm |
|
|
output type |
AC three phase/single phase |
|
|
Motor |
brushless |
|
|
Frequency |
<3% |
|
|
Frequency at stable state: |
<0.5% |
|
|
Frequency deviation at instantaneous state |
≤+10% |
|
|
Frequency return time |
≤3s |
|
|
Voltage deviation at stable state |
≤±1% |
|
|
Voltage deviation at instantaneous state |
≤+20% |
|
|
Voltage return time |
≤4s |
|
|
Voltage modulation |
≤0.3% |
|
|
Engine Specitions |
||
|
Engine type |
ISUZU, CUMMINS, STEYR |
|
|
Engine Output |
10kw -1100kw |
|
|
Norminal speed |
1500/1800RPM |
|
|
Number of cylinder |
4.6.12 |
|
|
Oil recommended (natural gas) |
<0.22 m3/kw@h |
|
|
Oil recommended (biogas) |
CE class |
|
|
Lube oil filling quantity |
min. 19 l, max. 22 l |
|
|
Max. lube oil consumption |
0,4-0,6 g/kWh |
|
|
Compression ratio |
11.5:1 |
|
|
Ignition point |
1-5-3-6-2-4 |
|
|
Engine weight (dry) |
200-1200KG |
|
|
Alternator specifitions |
|
|
|
Synchronous alternator |
Marthon .Stamford |
|
|
Nominal apparent power |
10kw -800kw |
|
|
Nominal active power |
10kw -800kw |
|
|
Nominal voltage |
400/231 VAC, 50 Hz |
|
|
Harmonic distortion (no load/ linear balanced load |
<1.8% / < 5% |
|
|
Dir. axis transient (X′d) |
11,0% |
|
|
Dir. axis subtransient (X"d) |
6,6% |
|
|
Quad. axis subtransient (X"q) |
7,2% |
|
|
Transient time constant (T′d) 100 ms |
100 ms |
|
|
Sub-transtime constant (T"d) |
10 ms |
|
|
Generator weight |
120KG-1200KG |
|
|
Bearing number |
1&2 |
|
