Famous Brand 250kVA Cummins Container Diesel Generator

Prod Model:	RT
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Power:	200-600kv
Voltage:	400/230V
Frequency:	50/60Hz
Color:	Customized
Type:	Basic Diesel Generator
Installation Method:	Portable
Stroke:	Four Stroke
Cooling Method:	Water Cooling
Output Type:	AC Three Phase

Product Description

Both standard and soundproof gensets are available under container type.
Main characteristics as follows:

1. Designed as per ISO standard, gensets below 1000kVA adopt 20'ft container size, and above 1250kVA adopt 40'ft container size;

2. With CSC/CCS certificate, the complete container type gensets can be shipped by shipping lines, thus the shipping cost saved;

3. Two flameproof lights fixed inside of the container and another one fixed in the control panel, enabling easy operation and maintenance;

4. Container can be open from both front and back, doors in two sides and one ladder on one side;

5. All hinges, locks, screws are made of stainless steel, the iner part of the container genset is fixed with waterproof accessory;

6. Control panel and output panel on the same side of container, making it is easy for operation and maintenance.

7. Fix PMG (Permanent Magnet Generator) assures the quick start and stable power supply;

8. Special design on fuel tank, fuel supply pipes, oil drain and muffuler, etc.

9. High performance soundproof materials are used for container type, which is flameproof, durable, and efficient on noise reduction.

Optional components: Automatic fuel make up system, coolant make up pump, double fuel & water separateor, synchronizing control system, etc.

1	Power	KVA/KW	250/200
2	Voltage	V	400/230
3	Frequency	HZ	50/60
4	Speed	RPM	1500/1800
5	Power factor		0.8
6	Ambient temp	ºC	40
7	Altitude	M	1000
8	Cooling method		A/W
9	100% load fuel consumption	L/wh	≤0.25
10	Phase		3 Phase
11	Protection grade		lp23
12	Insulation class		H
13	Temperature rise		H
14	Engine Model	Cummins	6LTAA8.9-G2
15	Generator Model	BOHUA	274K
