| Prod Model: |
LHNG300 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Model: |
Power Generator Natural Gas Generator |
| Name: |
Power Generator Natural Gas Generator |
| Brand: |
Lvhuan Power |
| History: |
Since 2008 |
| Staff: |
Over 250 People |
| Technology Engineer: |
Over 100 People |
| Factory Area: |
Over 40000m2 |
| Feature Product: |
Gas Generator and Diesel Generator |
| Main Products: |
12V190 Series Engine for Gas and Diesel |
| OEM: |
Yes |
| Gas Source: |
Natural Gas |
| Certification: |
Cec |
Product Description
Shandong Lvhuan Power Equipment Co, . Ltd.
WE DEVOTE OURSELVES TO GAS POWER GENERATION.
1. Company Introduction
Since 2008
Factory area over 40000m2
Starff over 260 employees
Technicians over 100 people
website www.lvhuandongli.com
2. Scope of Application
Waste to electricity, by farm waste biogas project, industry water waste biogas project, landfil project to get the biogas and realize the electricity generation.
3. Advantage
--Advanced configuration keep accurate ans stable working condition under high speed working speed
--High generalization, easy maintenance, low maintenance cost.
--Economical, low operating cost
--Reduced the carbon deposition on the wear of the engine cylinder and the valve to prolong the using life of the genset.
--Adopt one of the world's most advanced gas control technology, fully available to the characteristics of fuel gas.
--Powerful low pressure gas SPI (single point Injection) system used for various supercharger premixed engine.
--Suitable for differnt concentration methane and propane, variety of quality gas.
--Precise air-fuel ratio rarefied combustion control and Generator speed/load control
--Realize lean burn, reduce the intake pipe tempering and improved efficient to reduce the heat load.
4. Requirements For Natural Gas Genset Working Condition
Within 1m from pressure regulating valve of gas intake
--The ratio of CH4 in natural gas ≥70%
--Pressure of natural gas: 80-200kpa, rate of pressure change ≤ 1kpa/min
--H2S ≤ 20mg/Nm3
--Impurity particle size ≤ 5μm, impurity content ≤ 30mg/Nm3
--Moisture content ≤ 40g/Nm3
5. High Configuration
--Ignition system: ALTRONIC(USA)
--Starting system: DC24V electric motor.
--Mixer: IMPCO(USA)
--Sparking plug:STITT
--Engine Control System: Woodward(USA), HEINZMANN(Germany)
--Electric Control System: ComAp(Czech), Deepsea(UK)
--Alternator: Siemens, LEROY-SOMER, Marathon
6. Certificate
We have CE, ISO14001, ISO9001 and CEC certificate to keep the good quality. Please contact us for more details.
7. Service
(1) 24 hours- technology support service and the promptly reply
(2) Professional engineer team and strong technology support
(3) Customized design based on real situation
(4) Detailed and professional layout drawing, installation drawing and other drawing required by the customers supplied
(5) Engineer service on site
(6) Free training in Factory
(7) Equipment test before delivery
(8) One year guarantee period and lifetime service
(9) Spare parts lifetime supplied
8. Accessories
1) Application scope of the Accessories, such as 12v190, 8v190, 6190, 6135 and other engine types.
2.)All parts were from original factories or professional factories, complete in specification, keep good quality.
Sincerely welcome to visit our factory and build future cooperation relationship.
| Natural gas generator list |
| Gen-set mode | Prime power | Continuous power | Engine Mode | Displacement |
| LHNG10 | 10kw | 8kw | LH2100 | 1.80L |
| LHNG20 | 20kw | 16kw | LH4100 | 3.61L |
| LHNG30 | 30kw | 24kw | LH4105 | 4.32L |
| LHNG40 | 40kw | 32kw | LH6105 | 6.45L |
| LHNG50 | 50kw | 40kw | LH4135 | 8.58L |
| LHNG60 | 60kw | 48kw | LH4135 | 8.58L |
| LHNG70 | 70kw | 56kw | LH6135 | 12.8L |
| LHNG80 | 80kw | 64kw | LH6135 | 12.8L |
| LHNG90 | 90kw | 72kw | LH6135 | 12.8L |
| LHNG100 | 100kw | 80kw | LH6135 | 12.8L |
| LHNG120 | 120kw | 100kw | LH12V135 | 25.75L |
| LHNG150 | 150kw | 120kw | LH12V135 | 25.75L |
| LHNG180 | 180kw | 144kw | LH12V135 | 25.75L |
| LHNG200 | 200kw | 160kw | LH12V135 | 25.75L |
| LHNG300 | 300kw | 240kw | LH6190 | 35.70L |
| LHNG400 | 400kw | 320kw | LH12V190 | 71.45L |
| LHNG500 | 500kw | 400kw | LH12V190 | 71.45L |
| Parameter of natural gass generator |
| Rate Voltage | 400V/230V |
| Phase | 3Phase 4 wires |
| Rate Frequency | 50HZ/60HZ |
| Power Factor | 0.8 |
| Voltage Regulating Range | 95%-105% |
| Voltage Steady State | ≤±2% |
| Voltage Transient State | ≤±10% |
| Voltage Settling | ≤1S |
| Voltage Volatility | ≤±0.5% |
| Frequency Steady State Regulation Rate | ≤0.5% |
| Frequency Transient State Regulation Rate | ≤±10% |
| Heat Consumption | 10mj/kw.h |
| Pressure | 5-20kpa |
| Intake Mode | Natural intake |
| Sparking Mode | Sparking plug |
| Voltage Regulation Mode | automatic |
| Speed Regulation Mode | Electronic speed regulation |
| Lubricating Mode | Pressure and splash |
| Cooling Mode | Closed/open circulating water cooling |
| Starting Mode | 24V electric motor |
| Overhaul Time | ≥30000h |
| Noise | ≤105aB(A) |
| Exhaust Temperature | ≤650°C |
FAQ
1) What are the continous power and the standby power?
It depends on the hours the generator set works per day.
And 0.8*standby power = continuous power.
2) How long is the warranty?
One year
3) Do you provide installation? commissioning? and training?
Yes
4) Your engineer can go abroad?
Yes
5) Can you supply the spare parts?
Yes
6) Can you provide the turnkey project?
Yes
