Gas Diesel Generator Engine Spare Parts

Name: Gas Diesel Generator Engine Spare Parts
Brand: aboutgenerator.com
SKU: 694406532
Availability: InStock
Rating: 4.6 (81 reviews)

Price:	US $ 11000/Set
Trade Terms:	FOB,CFR,CIF
Min Order:	1/Set
Pay Type:	L/C,T/T,D/P,Paypal,Money Gram

Contact Supplier

Shandong Lvhuan Power Equipment Co., Ltd.

Showroom Product Company Profile

Prod Model:	diesel engine spare part
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Name:	Gas Diedel Generator Engine Spare Part
Applied:	Diesel and Gas Engine 190 Series
Delivery Date:	5-7 Days
MOQ:	1 PCS
Package:	Carton or Plywood Case
Shipment:	Air, Sea and Train

Product Description

Gas diesel generator engine spare part

Applied gensets:
1. JDEC Chidong /Shengdong engine gas and diesel
2. 190 series: 4190,6190,8190,12v190,16v190
3. 100% original
4. All spare parts on engine available.

Piston and connection rod assembly:

Ref. No.	Part Number	Description	Z12VB.05.00-Qty
1	12VB.05.09B	Compression ring (top)	1
2	Z12VB.05.11	Compression ring	2
3	Z12VB.05.20	Spring expander oil ring	1
4	Z12VB.05.01C	Piston	1
5	Z12VB.05.08A	Piston pin	1
6	Z12VB.05.14	Retain, piston pin	2
7	Z12VB.05.10.07	Dowel pin	1
8	Z12VB.05.10.02	Connection rod cap	1
9	Z12VB.05.10.03	Connection rod bolt	4
10	Z12VB.05.10.05	Connection rod bearing, lower	1
11	Z12VB.05.10.04	Connection rod bearing, upper	1
12	Z12VB.05.10.06	Washer	4
13	Z12VB.05.10.09	Connection rod nut	4
14	Z12VB.05.10.01	Connection rod	1
15	Z12VB.05.10.08	Small end bushing	1

Piston and connection rod assembly photos:

Cylinder head assembly

Ref. No.	Part Number	Description	12VB.03.00B-Qty
1	GB894	Retainer 30/30	2
2	12VB.03.10.03	Rocker arm,exhaust /	1
3	12VB.03.10.06	Plug/	5
4	12VB.05.50.01	Bulb head,rocker arm /	2
5	12VB.03.10.02	Bushing, rocker arm /	2
6	12VB.03.10.04	Shaft, rocker arm /	1
7	12VB.03.50.06	Plug/	1
8	12VB.03.09B	Stud,rocker arm/	1
9	GB93	Washer 14 / 14	3
10	Q/JC11013	Nut M141.5/141.5	3
11	12VB.03.04	Stud /	2
12	12VB.03.10.05A	Seat, rocker arm/	1
13	12VB.03.10.01	Rocker arm,inlet/	1
14	12VB.03.45	Nut/	2
15	12VB.03.44	Flange/	1
16	12VB.03.47	Stud /	2
17	12VB.03.44	Sleeve/	1
18	12VB.03.80.07	Seal ring /	2
19	12VB.03.80.06	Sleeve,injector/	1
20	12VB.03.53B	Screw /	4
21	12VB.03.51	Gasket /	1
22	12VB.03.80.01A	Cylinder head /	1
23	12VB.03.80.10	Plug subassembly	2
24	12VB.03.80.08	Zinc block/	2
25	12VB.03.80.20	Plug subassembly	2
26	Q/JC14009	Cooper washer30/30	1
27	12VB.03.80.11	Plug	1
28	12VB.03.80.05	Seat,inlet valve /	2
29	12VB.03.37A	Inlet valve /	2
30	12VB.03.80.04	Seat, exhaust valve/	2
31	12VB.03.22	Exhaust valve /	2
32	12VB.03.29	Plug /	1
33	12VB.03.80.09	Zinc block /	2
34	GB898	Stud M 1030/M1030	6
35	GB848	Washer 10/10	8
36	GB93	Washer 10/10	8
37	GB6170	Nut M10/ M10	6
38	12VB.03.80.02	Valve guide/	4
39	12VB.03.19	Spring seat,lower/	4
40	12VB.03.17A	Valve spring, inner /	4
41	12VB.03.17A	Valve spring, OUTER /	4
42	12VB.03.15	Spring seat, upper/	4
43	12VB.03.16A	Split collet /	4
44	GB848	Washer 14/14	4
45	GB893	Internal retainer 25 / 25	4
46	12VB.03.70.01	Fork cift /	2
47	12VB.03.70.03	Dowel pin /	2
48	12VB.03.80.03	Plug /	1
49	12VB.03.70.04	Wire retainer /	2
50	12VB.03.70.02	Guide rod/	2
51	12VB.03.30B	Bulb head, rocker bridge /	2
52	12VB.03.90B	Adjusting screw subassembly/	2
53	12VB.03.03B	Rocker bridge /	2
54	12VB.03.60B	Adjusting screw subassembly/	2
55	GB6173	Nut M141/M141	4
56	GB5782	Bolt M830/M830	4
57	GB848	Washer 8/8	4
58	12VB.03.02	Upper cover,cylinder head /	1
59	12VB.03.11	Seal ring I/I	1
60	GB5782	Bolt M10*100/I	4
61	12VB.03.14E	Lower cover,cylinder head /	1
62	12VB.03.12A	Seal ring II/II	1

FAQ:
How to choose the right model?
1. Fuel type: gas or diesel
2. Power in Kilowatt
3. Engine number
4. Spare parts photo, function, weight, item number, Eg.: 3032451 Ring Oil.

Our Services :
1.Spare parts service:
A.All spares parts on our gensets supplied by us. 100% original.

Please feel free to ask question and quotation.
Mob: +86-15966309493

Shandong Lvhuan Power Equipment Co., Ltd. is a manufacturer which specially produces internal-combustion gas engine generator sets and gas engines, with registered capital of more than RMB10 million, annual turnover of RMB100 million, over 200 staff, beautiful scenery and convenient transportation. Our factory mainly specializes in the design, research, production, sale, installation and technical service of gas generator sets and diesel generator sets. Our company has strong specialty, powerful technical force, a complete production plant, advanced processing technology, mature inspection method and a strict test system.

Our products include 105, 135 and 190 series base engines. The output power ranges from 10kw to 500kw. The gensets can be used for biogas, natural gas, oil associated gas, coal mine gas and mash gas produced by burying rubbish and sewage disposal.

We manage our company by ISO9001 system strictly. Gas engines and alternators are environment-friendly products.

Our philosophy is "Only pay attention to supplying stronger power to you". More importantly, combining with our continuous technological innovation and hard work, we believe that you will choose our company and keep a long-term business relationship with us!
