| Prod Model: |
XD-20KW-900R |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Voltage: |
Customize |
| Shaft: |
Customize |
| Output Frequency: |
50/60Hz |
| Phase: |
Three Phase |
Product Description
Diesel generator, gas generator, also can use for wind turbine and hydro turbine system, 1500rpm 1800rpm 1000rpm, 750rpm 900rpm all available
| Power(KW) | AC voltage(V) | speed(RPM) | poles | frequency | Rated torque(NM) | Start torque(NM) | current(A) | efficiency | weight |
| 20 | 120 | 900 | 8 | 60 | 212.2 | 4.2 | 103.5 | 93.80% | 170 |
fficient permanent magnet generator or charger, optimal design, compact structure. No carbon brushes, no excitation, no sparks. Do not need to replace the carbon brush, protection class: IP44, water, mud, dust will not enter the motor, long life, especially for vehicles needs.
non-excited winding, high strength rotor, the motor can reach high speed.
no excitation control box, simple structure, reliable.
Small volume, light weight, energy density, for a specific occasion.
In the entire speed range motors are operating efficiently, saving energy.
motor rare earth magnets embedded in particular for turbulence, repeated start, Reversible operating requirements.
motor is cooled by air or water cooled, low temperature, high-speed motor oil imported bearings, maintenance-free, high reliability and long life motor.
need to change the motor under voltage, speed, power and other parameters, can change the motor shape, can be used spline shaft extension, biaxial extension, aluminum shell, etc. front only the output port
Xinda Green Energy Co., Limited is specialized in handling the business of vertical and horizontal wind turbine generator, various kind of permanent magnet generator(0.05-3000kw), speed from 20rpm-20000rpm, both vertical and horizontal, small hydro turbine system(low head and higher head), wind solar hybrid system, high efficiency high seepd permanent magnet motor, street lamp and so on
