| Prod Model: |
LHNG400= |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Keywords: |
Natural Gas Generator Set |
| Cylinder Number: |
V Shape, 12 Cylinders |
| Cylinder Diameter: |
190mm |
| Stroke: |
210mm |
| Displacement: |
71.45L |
| Rated Speed: |
1000r/Min |
| Phase: |
AC 3-Phase, 4 Wire |
| Rated Frequency: |
50/60Hz |
| Gas Source: |
Natural Gas |
| Power: |
20-700kw |
Product Description
Natural gas turbine powered generator set is an ignition type gas machine which uses high calorific value natural gas as fuel. On the basis of the supercharged model increased the pressurization system and intercooler system, cooling system adopts high and low temperature separate cycle, high temperature circulating cooling cylinder, body, cylinder cover, low temperature circulation cooling pressurized gas, air and oil cooler.
| Parameter of Natural Gas Generator Set |
|
| Model Number (Engine Type) | LHNG10-500 |
| Brand Name | LVHUAN |
| Prime Power/Standby Power | 10KW/500KW |
| Rated Speed | 1500/1800RPM |
| Rated Frequency | 50/60Hz |
| Rated Voltage | 400V/230V |
| Phase | AC 3-Phase, 4 wire |
| Voltage Stability | ≤±2% |
| Voltage transient | ≤±10% |
| Voltage Stable time | ≤1s |
| Heat consumption | ≤11mj/kw.h |
| Lubricant consumption | ≤1.0g/kw.h |
| Engine Capacity | 25.8L |
| Cylinder Number | 12 |
| Cylinder Bore | 135mm |
| Stroke | 150mm |
| Starting System | DC 24V electric motor |
| Cooling method | water cooler |
| Lubricant method | Passive and flying lubricant |
| Isolation class | H |
| Protection | IP23 |
| Alternator | Chinese Stamford |
| Power Factor | 0.8 lagging |
| Exciting method | brushless |
| Colour | your choice |
| Certificates | ISO 9001:2008, CE |
| Warranty | 1 year or 1000 running hours which arrives first |
| Type | Open |
| Control system | Automatic alarm system |
| Size | 3250x1450x2140mm |
| Weight | 3200kg |
Pre-sales service:
1 We value every inquiry sent to us, ensure quick competitive offer within 12
hours.
2 We cooperate with customer to design and develop the new products. Provide
all necessary document.
3 We are a sales team, with all technical support from engineer team.
Punctual delivery time:
4 We put your order into our tight production schedule, ensure your punctual
delivery time.
5 Production / inspection report before your order packed.
6 Shipping notice/ insurance to you as soon as your order is shipped.
After sales service:
1 We respect your feed back after receive the goods.
2 We provide 12-24 months warranty after goods arrive.
3 We promise all spare parts available in lifetime use.
4 We resolve your complain within 48 hours.
Shandong Lvhuan Power Equipment Co., Ltd. is a manufacturer which specially produces internal-combustion gas engine generator sets and gas engines, with registered capital of more than RMB10 million, annual turnover of RMB100 million, over 200 staff, beautiful scenery and convenient transportation. Our factory mainly specializes in the design, research, production, sale, installation and technical service of gas generator sets and diesel generator sets. Our company has strong specialty, powerful technical force, a complete production plant, advanced processing technology, mature inspection method and a strict test system.
Our products include 105, 135 and 190 series base engines. The output power ranges from 10kw to 500kw. The gensets can be used for biogas, natural gas, oil associated gas, coal mine gas and mash gas produced by burying rubbish and sewage disposal.
We manage our company by ISO9001 system strictly. Gas engines and alternators are environment-friendly products.
Our philosophy is "Only pay attention to supplying stronger power to you". More importantly, combining with our continuous technological innovation and hard work, we believe that you will choose our company and keep a long-term business relationship with us!
