| Prod Model: |
Hino P11C J08E |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Engine Style: |
P11c J08e |
Product Description
Hino Truck Water Pump Assembly
Hino Diesel engine parts turbo booster is original made by Hino company China branch
HINO Specification
BRAND | HINO |
| MODEL | J08E-UP | J08E-US | J08E-UT | J08E-UU |
| EMISSION | EuroIII |
| INTAKE | turbocharger and intercooler |
| No. of valve for each cylinder. | 4 |
| NO.Cylinder-bore×stroke mm | 6-112×130 |
| displacement L | 7.684 |
| rated power/speed KW(Ps)r/min | 222(300)/2500 | 210(285)/2500 | 191(260)/2500 | 180(245)/2500 |
| max torque/ speedN-m/r/min | 1000/1500 | 872/1500 | 800/1500 | 745/1500 |
| minimum fuel consumption g/kW.h | 193 | 200 |
| Fuel inection system | electrical common rail |
| cylinder liner | dry |
| camshaft | top |
| timing gear system | rear |
| net weight kg | 670 |
| Dimension (L*W*H)mm | 1137×910×930 |
| Noise dB(A) | 97
|
BRAND | HINO |
| EMISSION | EuroII | EuroIII |
| MODEL | P11C-UK | P11C-UL | P11C-UH | P11C-UJ | P11C-UR |
| INTAKE | turbocharger and intercooler |
| TYPE | direction inject |
| No. of valve for each cylinder. | 4 |
| NO.Cylinder-bore×stroke mm | 6-122×150 |
| Displacement L | 10.52 |
| Rated power KW(Ps)r/min | 240(325)/2100 | 259(350)/2100 | 240(325)/2100 | 259(350)/2100 | 280(380)/2100 |
| MAX TorqueN-m/r/min | 1420/1100 | 1460/1100 | 1420/1100 | 1460/1100 | 1600/1300 |
| Minimum torque N-m/r/min | 700/600 | 900/600 |
| Minimum fuel consumption g/kW.h | 196 | 195 |
| Fuel inection system | in-line fuel pump | electrical common rail |
| cylinder liner | dry |
| Net weight kg | 1070 |
| Dimension (L*W*H)mm | 1362×1018×1029 |
| Noise dB(A) | 96 | 96 |
JACA has been specialized in manufacturing diesel generators and accessories for more than 20years. It has knotted fast and extensive business ties with over 1000 clients both in China and abroad, and turned up as a leading player in the world generator area. JACA is the executive member of the China Chamber of Machnery & Electronics and an AAA grade company for bank credit entitled by the bank in China.
JACA has a wide range of qualified diesel generators for sale, including silent type diesel generator, open type diesel generator, portable diesel generator, trailer diesel generator, container diesel generator and diesel generator with Cummins, DEUTZ, Volvo, SME engine and Stamford, meccatte alternator and also with famous Chinese brand engines like SDEC, Kofo, Cangchai and etc.
JACA products are widely used in the application areas of industry, energy, chemistry, mine, hospital, building, transportation and water conservancy, etc. Power changes life! We are devoting ourselves to more power applications of diesel generator.
Customer first, good service, high quaity are our missions! We are looking forward to set up brand new business relationship with you in prosperous 2015!
