| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Products: |
Oxygen/Nitrogen |
| Size: |
3mx3m |
| Processing Customized: |
Yes |
| Type: |
Separating Plant |
| Condition: |
New |
Product Description
Product Description
PSA Oxygen Generator
Principles:
Customized PSA oxygen generator, purity 90-95% with no purification system, capacity from 1Nm3/h-50Nm3/h, pressure from 0.1bar to 200bar, uses zeolite molecular sieve as sorbent, produces oxygen by making use of the PSA principle. Professional energy saving design provided with each of oxygen generator system, low air consumption means more economical for customers.
The control system is provided, all the parameters can be read and the operation can be actualized by one touch only. Alarming system can work automatically when the purity, the capacity and pressure is lower than required, it means more reliable and more humanistic for customers.
Applications:
1. After the oxygen generator, the oxygen purification system is equipped to guarantee the quality of the O2 and removing dust, eliminating bacteria and stabilizing pressure to ensure the oxygen outputted stably and meeting medical standards.
2. Users only need to turn the start/stop button to gain the oxygen with designing required flow capacity and purity within 30 minutes.
3. Single line and double lines types are available for option. Users are suggested to choose the single line type when they only require a stable flow capacity; Choose double lines when demand is unstable and sometimes meet extra peak values.
Two years spare parts have been provided with the generators.
All goods will be commissioned before delivery, international service can be provided.
All the models can be customized, for more information, please do not hesitate to contact.
Company Information:
1. CYY Energy is professional cylinder, cylinder rack, storage tank, pump, air separation plant, LNG plant, cryogenic storage system and gas relevant equipments supplier. We provide the best service obsess over customer's demand. We believe our purpose is to create value for the customer. CYY Energy has advanced technical design ability, mature project management system, consummate and close-in after-sales service. Our production is widely used in steel, metallurgy, oil, chemical industry, machinery, environmental protection, electronic industry, medicine etc. So far, we have successfully delivered our equipments to all around the China, South-East Asia, Middle East, South America and Latin America. We have fostered a good company image all around the world.
2. Our products including CNG steel cylinder for vehicle, High pressure seamless steel gas cylinders, Fire-fighting cylinders, Accumulator shell and other cylinder products. The high pressure seamless steel gas cylinder can produced according to the standard such as ISO11439, ISO9809, JIS B8241, NZS5454, EN1964, DOT3AA, IS7285,GB17258,GB5099 and so on. CYY's products serve a wide application in automotive, chemical industries, firefighting, petro industries, energy, metallurgy, electronics, aerospace, nuclear energy and scientific research institute.
3. CYY has equipped with most advanced two pipe production lines with strongly technology, advance equipment and complete means on inspection. Our company can produce the max outside diameter of the pipe is 406mm. the annually capacity of CYY can be more than 350,000 cylinders and it will reach more than 1,000,000 cylinders after the new five production lines have been finished
4. CYY production and management are carried out by ISO9000 Quality Management System strictly and keep a good quality.
5. There are various kinds of gas cylinders for your choice and we can also design and manufacture any new type gas cylinder according to customers' requirement.
CYY Mission:
Supply the best Cryogenic Equipment and the relative services according to the customer's needs In the global market, which create famous brand for customers and keep the healthy development of the company and value added.
Service Positioning:
To challenge convention, meet market, perfect service and improve quality, CYY always places client supreme, and pursues service quality by implementing pre-sale service, during-sales service together with self-examination.
Welcome all clients to our company for visit!
Model
| Construction | Dimensions | Inlet& Outlet | Weight(Kg) |
| 1 | Four towers | 620*505*1260 | G1/4; G1/4 | 226 |
| 2 | Four towers | 1000*900*1500 | DN15; G1/2" | 418 |
| 3 | Four towers | 1000*950*1580 | DN15; G1/2" | 515 |
| 4 | Four towers | 1200*1100*1800 | DN15; G1/2" | 622 |
| Two towers | 1050*600*1700 | DN15; G1/2" | 433 |
| 5 | Four towers | 1300*1200*1750 | DN25; G1/2" | 694 |
| Two towers | 1100*600*1620 | DN25; G1/2" | 459 |
| 6 | Four towers | 1300*1200*1850 | DN25; G1/2" | 749 |
| Two towers | 1100*600*1850 | DN25; G1/2" | 502 |
| 7 | Four towers | 1400*1300*1800 | DN25; G1/2" | 853 |
| Two towers | 1200*650*1650 | DN25; G1/2" | 586 |
| 8 | Four towers | 1400*1300*1850 | DN25; G1/2" | 937 |
| Two towers | 1200*650*1820 | DN25; G1/2" | 640 |
| 10 | Four towers | 1500*1400*1850 | DN25; G1/2" | 1076 |
| Two towers | 1300*700*1750 | DN25; G1/2" | 758 |
| 15 | Four towers | 1700*1550*2120 | DN40; G1" | 1352 |
| Two towers | 1400*750*2120 | DN40; G1" | 923 |
| 18 | Four towers | 1800*1650*2060 | DN40; G1" | 1531 |
| Two towers | 1550*800*2060 | DN40; G1" | 1062 |
| 20 | Four towers | 1800*1650*2250 | DN40; G1" | 1618 |
| Two towers | 1550*800*2250 | DN40; G1" | 1130 |
| 25 | Four towers | 1800*1650*2700 | DN50; G1" | 1899 |
| Two towers | 1550*800*2700 | DN50; G1" | 1327 |
| 30 | Four towers | 1900*1750*2700 | DN50; G1" | 2166 |
| Two towers | 1650*850*2700 | DN50; G1" | 1524 |
| 35 | Four towers | 2100*1900*2600 | DN50; G1" | 2424 |
| Two towers | 1750*900*2600 | DN50; G1" | 1686 |
| 40 | Four towers | 2100*1900*2900 | DN50; G1" | 2633 |
| Two towers | 1750*900*2900 | DN50; G1" | 1847 |
| 45 | Four towers | 2200*2000*2850 | DN65; G1" | 2831 |
| Two towers | 1850*950*2850 | DN65; G1" | 2167 |
| 50 | Four towers | 2100*1950*3100 | DN65; G1" | 3179 |
| Two towers | 1850*950*3100 | DN65; G1" | 2325 |
| 55 | Four towers | 2300*2100*3000 | DN65; G1" | 3328 |
| Two towers | 1900*1050*3000 | DN65; G1" | 2411 |
| 60 | Four towers | 2300*2100*3210 | DN65; G1" | 3599 |
| Two towers | 1900*1050*3210 | DN65; G1" | 2615 |
