| Prod Model: |
LTP2500 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Phase: |
Single-Phase |
| Warranty: |
1 Year |
| Crankcase: |
Magnesium Alloy |
| Use: |
Generating for Home, Shop, Camp etc |
| Output Type: |
AC Single Phase |
Product Description
1. Easy to start (within 3-5 times for recoil starter, within 30S for electric starter)
2. Stable (voltage and frequency fluctuate smoothly)
3. Clear, Lower emission(no smoke, no smell, good protection for your health and environment)
4. Cost saving (save 30%~70% operation cost than oil powered generator set)
5. Longer serving life (25% longer than gasoline oil powered generator set )
6. Safety and Convenience for operation (The only way to close the generator is to cut off the gas which make the operation safe. )
7. Easy for maintenance
GENSET Type Brushless, Revolving Magnetic Field, Self-excitating, 2 Poles
Voltage Regulator Condenser Type
Frequency Hz 50 60 50 60 50 60 50 60 50 60
Max. AC Output kVA 2.3 2.5 2.8 3 4.5 5 5.5 6.5 8.5 9.5
Rated AC Voltage V 110, 120, 220, 230, 110/220, 120/240
Rated AC Output kVA 2 2.3 2.5 2.8 4 4.5 5 5.5 8 8.5
Power Factor cosφ Cosφ =1
ENGINE Model YL168FC YL169FC YL182FEC YL188FEC YL190FEC
Type Forced Air-cooled, $-stroke, OHV
Displacement ml 163 196 337 389
Max. Output 5.5HP/4000rpm 6.5HP/3600rpm 11HP/4000rpm 13HP/4000rpm 15HP/4000rpm
Fuel Natural Gas, LPG, Marsh Gas (Unleaded Gasoline)
Compression Ratio 8: 01
Fuel Tank Capacity l 12 22
Continuous. Hours h 11 9.5 10 9 9.2 9.5 8.2 7 8 7
Oil Engine Oil SD or Higher
Oil Capacity l 0.6 0.6 1.1 1.1 1.1
Ignition System T. C. I
Starting System Recoil Recoil-self
Noise Level (7m) dB 65 68 65 68 70 73 72 75 72 75
DIMENSION Net L*W*H mm 545*425*440 565*425*440 674*510*532
Package L*W*H mm 560*440*460 580*440*460 700*530*550
N. W/G. W kg 43/45 45/48 75/78 84/87 87/90
20FT unit 265 225 140 140 140
|
Model |
LT
2000LPG |
LT
2500LPG |
LT
3000LPG |
LT 3500LPG |
LT
4500LPG |
LT 5500LPG |
LT 6500LPG |
|
Generator |
Type |
Self-excitating, 2-pole, Single-phase |
|
Voltage Regulation |
AVR |
|
Frequency(Hz) |
50/60 |
|
Max. AC Output(KVA) |
1.8/2.0 |
2.0/2.2 |
2.0/2.2 |
2.5/2.7 |
3.5/3.7 |
4.0/4.5 |
5.0/5.5 |
|
Rated AC Voltage(V) |
110/120/220/230/240 |
|
Rated AC Output(KVA) |
1.5/1.8 |
1.7/2.0 |
2.2/2.5 |
2.8/3.0 |
3.2/3.5 |
3.5/4.0 |
4.5/5.0 |
|
Power Factor cosφ |
1.0 |
|
LPG Engine |
Model |
168LPG |
168LPG |
200LPG |
240LPG |
270LPG |
340LPG |
390LPG |
|
Type |
OHV Forced Air-cooled 4-stroke |
|
Displacement(ml) |
163 |
163 |
196 |
242 |
270 |
337 |
389 |
|
Max. Output(HP) |
5.0 |
5.0 |
6.0 |
7.0 |
8.0 |
10.0 |
12.0 |
|
Fuel |
Liquefied petroleum gas |
|
Oil |
SF or Higher grade |
|
Oil Capacity(L/oz) |
0.6 |
1.1 |
|
Ignition System |
T. C. I |
|
Starting System |
Recoil and hand-operated/Electric start |
|
Standard Feature |
Fuel Gauge |
0 |
0 |
0 |
0 |
0 |
0 |
0 |
|
Voltmeter |
0 |
0 |
0 |
0 |
0 |
0 |
0 |
|
AC Circuit Breaker |
0 |
0 |
0 |
0 |
0 |
0 |
0 |
|
Engine Switch |
0 |
0 |
0 |
0 |
0 |
0 |
0 |
|
AC Socket |
0 |
0 |
0 |
0 |
0 |
0 |
0 |
|
DC Output 12V/8.3A |
0 |
0 |
0 |
0 |
0 |
0 |
0 |
|
DC Circuit Breaker |
0 |
0 |
0 |
0 |
0 |
0 |
0 |
|
Optional Features |
Remote Control |
+ |
+ |
+ |
+ |
+ |
+ |
|
|
GFCI Socket |
+ |
+ |
+ |
+ |
+ |
+ |
+ |
|
Hours Meter |
+ |
+ |
+ |
+ |
+ |
+ |
+ |
|
Handle& Wheels |
+ |
+ |
+ |
+ |
+ |
+ |
+ |
|
Package |
Dimension(L× W× H)(mm) |
600× 450× 470 700× 525× 580 |
|
G. W(kg/lbs) |
42 |
42 |
44 |
69 |
74 |
77.5 |
86 |
|
N. W(kg/lbs) |
40 |
40 |
42 |
65 |
70 |
73.5 |
82 |
LANDTOP GROUP is specialized in manufacturing and exporting a wide range of electromechanical products, covering Alternators, Generators, Electric Motors, Water Pumps, etc.
With years of development, LANDTOP has developed into a large-scale, modern, comprehensive and international company. Our sales department is located in Fuzhou City (Fuzhou Landtop Co., Ltd. ), a sea-port city, enjoying convenient transportation network. We also have our own factory in Fu'an City (Fu'an Landtop Power Co., Ltd. ). Our international center is located in Hongkong(Hongkong Landtop Group Ltd. ). Our group is equipped with a great number of precise assemble lines, integrated testing systems and checkout equipment. We have professional engineers, skilled QC members, experienced salesmen and the best after-sales services. The current annual export production value is over 15 million US dollars.
We are always making great efforts to achieve the integration of manufacture and sale. We are able to meet our customers' demands, providing them with superior quality products. Our products, owing to reasonable price, high efficiency and energy saving performance, are widely praised by clients in over 80 countries and regions, such as Europe, America, Southeast Asia, the Middle East, Africa, etc.
Professional R&D system, standard technology, a skilled QC team and the best management group can offer you firm guarantee. Our group is continuously making arduous efforts on innovation to better serve our customers. We ensure that our cooperation will bring a win-win benefit to both of us.
