| Prod Model: |
AA-NI1170N2P |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Dimensions: |
100-240VAC 24VDC |
| Height: |
1260mm/49.6" 1344mm/52.9" |
| Width: |
620mm/24.4" 620mm/24.4" |
| Depth: |
430mm/16.9" 850mm/33.5" |
| Power Requirement: |
100-240VAC 50/60Hz |
Product Description
Detailed Product Description
Technical Data Summary
Dimensions: 100-240Vac 24Vdc
Height 1260mm/49.6" 1344mm/52.9"
Width 620mm/24.4" 620mm/24.4"
Depth 430mm/16.9" 850mm/33.5"
Power Requirement 100-240Vac 50/60HZ
24Vdc(2 pcs 12Vdc internal batteries and
100-240Vac 50 HZ/60HZ charger included)
Power Consumption 70VA
Operating Temperature Range -20/-4 degree F to 70 / 158 degreeF
Compressed Air Input Range 145-217PSI/10-15bar /1000-1500kPa
Nitrogen Purity ≥95%
Nitrogen Output 170L/min(6cfm)@116PSI/8bar/800kPa
Absorption pressure
Maximum Nitrogen Pressure in Tank
145-174PSI/10-12bar/1000-1200kPa Adjustable
Operating Range 5-162PSI/0.3-11.2bar/35-1120kPa
Over Pressure Setting Range 0-29PSI/0-2.0bar/0-200kPa
Nitrogen Purges 0-9
Inflator Accuracy +/-1PSI/0.07bar/7kPa
Resolution 1PSI/0.1bar/5kPa
Units of Measurement PSI/bar/kPa
Specifications:
Generates nitrogen from your compressed air
Auto Shut-Off
2 Pre-Filters
118L/31.1gal(us)internal nitrogen storage tank
Adjustable over pressure setting(OPS)
Nitrogen purge and fill cycle (N2P)
Adjustable number of cycles
Adjustable lower purge pressure limit
Standard inflate to target
4 air outlets allow simultaneous inflation of up to 4 tires
Auto-Start inflation
Automatic zero drift adjustment
Remain at last setting
Comprehensive diagnostics and error reporting
Audible and visual end of the cycle signal indicators
Large backlight LCD display
Vandal resistant mechanical switches
4 Nos. *10M/32.8ft standard hoses with single clip-on open type chuck |
