| Prod Model: |
10kw |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Number Of Blade: |
Three Blade |
| Stress Way Of Blade: |
Lift Force |
| Rotating Shaft: |
Horizontal |
Product Description
Parameter
Rated power(W) 10000
Rated voltage(DCV) 240
Rated current(DCA) 42
Rotor diameter(m) 8.0
Blade material GFRP
Rotation direction Clockwise
Start-up wind speed(m/s) 2.5
Rated wind speed(m/s) 10
Cut-out wind speed(m/s) 16
Survival wind speed(m/s) 45
Net weight(T) 1.0
Wind turbine type Upwind
Rated Rotating speed(RPM) 180
Blades No. 3
Hydraulic tower height (m) 12
Yaw mechanism Electrical
Annual yield(kwh) 24000
Yaw mode Auto/manual
Efficiency 0.85
Wind turbine tilt-angle 6°
Protection mode -Yaw
-Hydraulic brake
-Dumpload
