| Prod Model: |
FD3.0-1000W |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Rated Rotated Speed(r/m): |
400 |
| Rated Power(w): |
1000 |
| Max Power(w): |
1500 |
| Output Voltage(v): |
48V |
| Number Of Blade: |
Three Blade |
| Stress Way Of Blade: |
Resistance |
| Rotating Shaft: |
Horizontal |
Product Description
Product performance characteristics
1. Low peed generator, use rare earth permanent magnet materials, strong overloading ability.
2. Use high-quality bearings, magnet and other components, the radiation heat is strong demagnetization rate is low.
3. The body is made of high-quality steel pipes or ductile iron, have a good anti-corrosion treatment, prevent wind sand, prevent salt spray and other erosion, suitable temperature -40 -60 environment.
4. The professional magnetic circuit design, incising wind speed of 2.5 m / s, lower wind speed you can generate electricity.
5. Rotary body part use a closed transmission slip ring, cable is not enwind.
6. Unique rudder angle pre-design, automatic precision alignment wind direction, to improve output power taking into account the speed regulation and strong winds to protect.
7. Wind wheel using fixed-distance, high-quality glass fiber reinforced plastics blade, start with low wind speed, strong wind resistance ability, utilization of wind energy up to 40% or more.
8. With overcharge, over-discharge, exchange unloading and short-circuit protection, DC-constant voltage charging, run the simple, non-artificial unattended and special maintenance.
9. To install small occupancy area and on the geology require low, in the hills, the beach, river bank, desert terrain, etc. Can be installed under the conditions of use.
10. Generator sets operation stable, reliable quality, the design life of 15 years, an investment and long-term benefits.
| Power(w) | 1000 |
| Blade diameter (m) | 3 |
| Rated Rotated speed(r/m) | 400 |
| Rated wind speed (m/s) | 8 |
| Rated power(w) | 1000 |
| Max power(w) | 1500 |
| Output voltage(v) | 48V |
| Start up wind speed(m/s) | 3 |
| Operating wind speed(m/s) | 3-25 |
| Security wind speed(m/s) | 40 |
| Height of tower (m) | 6 |
| Weight of top section (kg) | 83 |
| controller Parameter | 48V 60A |
| Inverter Parameter | DC48V user’s local voltage & frequency |
| tower pole type(mm) | 75*4 |
| 20container(sets) | 60 |
| 40container(sets) | 112 |
| Capacity and quantity of battery(reference) | 12V150AH 4pcs |
| can supply power for | ice box,washer,waterpump,tv,lighting,electric fan,charger |
We specialize in this field for several years, with the strength of wind turbines, with good quality and pretty competitive price. SHANDONG JIALI NEW ENERGY Co., Ltd founded in 1994, specialized in manufacturing wind turbines, the main products are 200W, 300W, 600W, 1KW, 2KW, 3KW, 5KW, 10KW, 20KW, 30KW, 50KW and 100KW wind turbines and small solar panels, wind solar hybrid systems. Products are exported to the United States, Germany, Britain, France, Pakistan, Indonesia, Mongolia, has a customers high praise.
