1000kVA Cummins Diesel Power Generator (KTA38-G2A)

Name: 1000kVA Cummins Diesel Power Generator (KTA38-G2A)
Brand: aboutgenerator.com
SKU: 716707775
Availability: InStock
Rating: 4.6 (22 reviews)

Price:	US $ 10000-150000/Piece
Trade Terms:	FOB,EXW,CIF
Min Order:	1/Set
Pay Type:	L/C,T/T,Western Union

Contact Supplier

Guangzhou Weilida Machinery & Electronic Co., Ltd.

Showroom Product Company Profile

Prod Model:	KTA38-G2A
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Rated Voltage:	230V/400V
Frequency:	50Hz/60Hz
Speed:	1500/1800rpm
Air Intake Method:	Turbocharged Inter Cooled
Alternator:	Stamford, Simens, Marathon, Farady
Control Panel:	Dse6020
Quality Control:	ISO/CE Certificate
Warranty:	1 Year or 1500 Running Hours
Cooling Method:	Water Cooling
Stroke:	Four Stroke
Installation Method:	Fixed
Type:	Self-Starting Diesel Generator
Output Type:	AC Three Phase

Product Description

As a big generator set OEM factory with 19-year export experience. We can pupply Diesel power Generator, Mobile Generator, Electric Generator, Natural Gas Generator under the famous brand of CUMMINS, DEUZT, CATERPILLAR, SHANGCHAI(SEDC), YUCHAI, with power ranging 0.65-3000kVA; AC alternator under the brand of STAMFORD, MARATHON, FARADAY and Siemens. We also offer spare parts for SFH, SEDC and HINO.
Hundreds in stock for immediate delivery.

Cummins generator set specification:
Cummins-As the world's largest independent engine manufacturer, Cummins Inc. was founded in 1919 and headquartered in Columbus, USA. Its product line includes diesel and alternative fuel engines. Cummins provides services to clients through its over 500 distribution agencies in 190 countries and territories with the 5200 dealers.

Soundproof/Silent box:
-Excellent ventilation
-Fuel tank mounted on baseframe for 12 Hours working
-Highly Corrosion Resistant construction
-Excellent Access for Maintenance
-Security and Safety
-1m<80DBA / 7m<70DBA

Control panel:
-Automatic control panel(AMF), LED display.
-Four protection systems
-Emergency stop
-DSE/COMAP/SMARTGEN/HARSON

Optional:
- Trailer type
- Soundproof / water proof
- ATS(automatic transfer switch)
- water Heater
- Parallel system
- Remote system

800kw/1000kva Cummins generator set Specification :
Genset Modle	DC800
Dimension(mm)	365016382040
Weight(kg)	4685
Prime Power(kw/kva)	800/1000
Standby Power(kw/kva)	880/1100
Rated current (A)	1440
Powerfactor(CosPhi)	0.8
Altitude	≤1000m
Base Fuel Tank	Eight hours(Standard)
Engine Features:
Engine model	KTA38-G2A
Type of Governor	Electronic governor
Type	12 cyclinder
Bore*Stroke(mm)	159*159
Compression ratio"	17.3:1
Voltageregulation	±0.5%
fuel consumption rate(g/kw.h)	≤203g/kw.h
Alternator Features:
brand	Stamford, Simens, Marathon, Farady at option
Voltage control	AVR
Numberofphase	3
Overspeed	2250RPM
Excitertype	AREP
Insulation class	H
protection class	IP22/IP23
Totalharmonics (TGH/THC)	< 3.5 %
Waveform NEMA = TIF	<50
Waveform I.E.C. = THF	<2%
Bearing	single
Coupling	Direct

One of the Leading Manufacturers of Diesel Generator Sets:

Founded in 1994, Guangzhou Weilida Machinery & Electronic is one of the leading manufacturers of diesel generator sets in China. Through our hard work, we have built long-term relationships with engine manufacturers such as Cummins, Deutz, Mitsubishi, Daewoo and Volvo etc. We are also the general agent of SDEC (Shanghai Diesel Engine Co. ) in Guangdong.

Developing New Items to Update Your Selection:

We have 20 R&D engineers with 19 years of experience. They develop new items to freshen up your options. We also employ 5 QC auditors with five to eight years of experience. They ensure all our products are free of defects. For your added assurance, a one-year warranty is offered.

Monthly Output of 300 Units:

Our ISO 9001: 2008-certified factory covers an area of 5, 000 square meters and houses over 100 workers. With such support, we have a monthly production capacity of 300 sets, which are mainly exported to Africa, the Middle East, Southeast Asia, and South and North America.

Inquire Today:

Our 7 sales representatives with two to five years of experience, They are available to help you in selecting the right generator for your operating environment. At Weilida, we are committed to providing the highest level of customer service, competitive pricing, speedy delivery and reliable products. Our ultimate goal is your satisfaction.
