| Prod Model: |
MINI300W |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Model: |
300W Wind Turbine |
| The Power: |
300W |
| Max Power: |
350W |
| Voltage: |
DC12/24V |
| Blades: |
Nylon Fiber |
| Working Temp: |
-40 Degree ~ +50 Degree |
| Survival Wind Speed: |
50m/S |
| Warranty: |
3years |
| Certificate: |
CE, RoHS, ISO9001:2008 |
| Packing Size: |
770*410*200mm |
| Rotating Shaft: |
Horizontal |
| Stress Way Of Blade: |
Resistance |
| Number Of Blade: |
Multiple-Blade |
Product Description
features
300w mini small portable wind mill for home use
3 / 5blades, built-in / without controller 4models for
choice
Bearing from "SKF" Sweden.
Stainless steel screw bolt from "THE".
Primary aluminum housing, not secondary aluminum.
Low start-up wind speed
High-efficient Generator
Perfect Wind Wheel System
Unique Design Of The Rudder
Damp-proof, sand-proof, Anti-rust, Anticorrosion
Easy installation, Free of maintenance, Long lifespan
over 15years.
300w mini small portable wind mill for home use
specification
Model | Mini300W-3 | Mini300W-5 |
| Rated power | 300 watts at 11 m/s |
| Max Capacity | 350watts |
| Voltage | 12, 24 VDC |
| Blades | 3 Pcs Nylon Fiber | 5 Pcs Nylon Fiber |
| Start-Up Wind Speed | 2.0 ( m/s) | 1.5 ( m/s) |
| Cut-In Wind Speed | 2.5(m/s) | 2.0(m.s) |
| Rotor Diameter | 1.16 m | 1.21m |
| Weight | 6.2 kg | 7.1 kg |
| Shipping Dimensions | 790x 430x 220 mm (8 kg) | 790x 430x 220 mm ( 9.3 kg) |
| Mount | 1.9 inch (48 mm) OD pipe |
| Turbine Controller (Optional) | Maximum Power Point Tracking, MPPT |
| Body | Cast aluminum |
| Overspeed Protection | Electronic torque control |
| Working temperature | -20ºC~ 120ºC |
| Certificate | ISO9001:2008 ,CE, RoHS |
| Survival Wind Speed | 50 m/s |
| Warranty | 3 year limited warranty |
300w mini small portable wind mill for home use
Product introduction
Ø Stainless steel screw bolt from "THE".
Ø Primary aluminum housing, not secondary aluminum.
Ø Low start-up wind speed
Low wind speed series wind turbines generate more than 60% effective power than the same rotor diameter wind turbine annually.
Ø High-efficient Generator
Three-phase permanent magnet synchronous wind turbine, more than 10% of the efficiency of ultra-GB, starting resistance, only be 1/3 of the GB limit, motor insulation rating class H insulation.
Ø Innovative Noise Reduction Technology
Start and product electricity at the 1.5m/s, noise only at 40db at 13m/s.
Ø Perfect Wind Wheel System
The wind turbine wheel are made of a low temperature resistance, aging high strength compound material, can cope with a variety of complex wind conditions, charge wind energy into electrical energy efficiently and sustainably..
Ø Unique Design Of The Rudder
Wind turbine rudders are ale to respond to the wind speed and wind direction flexibly, enhancing the efficiency of power generation.
300w mini small portable wind mill for home use
Warranty
3 years warranty time.
