| Prod Model: |
GGDC6000 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Rated DC Output: |
5.5kw |
| Max DC Output: |
6.0kw |
| Rated DC Voltage: |
36/48/V |
| Rated Current: |
140/110a |
| Output Type: |
DC |
Product Description
6.0KW Digital DC Gasoline Generator GGDC6000, with CE, GS, EPA certificate.
with this innovative digital DC generator of high efficiency, energy saving and environmental friendly, the running cost of telecommunications is greatly reduced. When there is no utility power, the DC output of digital DC generator ensures the load power supply and at the same time charges the battery, thereby meets the constant power demand for telecommunications devices.
Performance and features:
Energy-saving
Compared with traditional AC generator, DC generator are capable of reducing fuel consumption by 20%-25%
Convenient paralleling function
The DC generators can be paralleled together with two or more, without limitation on model or number. Appropriate power capacity and number of paralleling units can be selected to meet different loads.
Soft start
Current slowly rises after start to avoid the impact to communication loads and batteries. The max current can be steplessly and widely adjusted, which is applicable to the battery charging and load power supply for various base stations.
Large current, compact size and light weight
Compared with AC generator of same power with DC output through switch power supply, current will be larger by 52%.
Intelligent management on battery charging
Adaptable to quick charging. Prolong service life of accumulator. Charging process may be three steps: Constant flow, equalized charge and floating charge. The charging process complies with technical standards of YD/T 799-2000 "Technical Requirements and Test Methods of VRLA Battery for Telecommunication".
High automation
RS232/RS485 communication port can provide with open communication protocol, incorporate with the power environmental centralized monitoring network and realize remote control.
|
DC-Generator |
MODEL |
GGDC6000 |
|
Type |
Permanent magnet, brushless, bearing-less |
|
Voltage Regulate |
Automatism electronic regulate |
|
Rated Dc Output |
5.5KW |
|
Max Dc Output |
6.0KW |
|
Voltage output regulation |
0.5-1.0VDC |
|
Ripple quotiety |
150mV (when connecting on the battery) |
|
Rated Dc Voltage |
48V |
|
Rated Current |
105A |
|
Run output Dc Voltage |
52.5V |
|
Gasoline Engine |
Model |
SG390FA |
|
Type |
OHV Forced Air-cooled, 4-Stroke |
|
Bore× Stroke |
1-88× 64mm |
|
Air cleaner |
Semi-dry double silent type |
|
Cooled way |
Air-cooled |
|
Displacement |
389ml |
|
Compression ratio |
8.2: 1 |
|
Max torque |
27.5/2500 N. m / rpm |
|
Ignition system |
Non-contact transistorized ignition (T. C. I) |
|
Spark plug gap |
0.7mm |
|
lubricating oil |
SF or Higher Grade |
|
lubricating oil capacity |
1.1L |
|
Lubrication system |
Pressure Splash |
|
Fuel consumption |
374(g/KW-hour) |
|
Power output |
13/3600 (HP/ rpm) |
|
DC-Generator-Set |
Fuel |
Unleaded gasoline |
|
Starting system |
hand-operated/Electric start |
|
Noise level |
72dB |
|
Oil alarm |
No lube oil Auto stop safekeeping |
|
continuous operating |
11h |
|
Fuel capacity |
25L |
|
Front panel control system |
One-DC Output Socket, DC Output Pilot lamp. Over loading protect& Malfunction Pilot lamp |
|
Dimension L× W× H |
700*560*590mm |
|
Gross/ Net weight |
70/68 |
|
Unit (20FT) |
120 |
