| Prod Model: |
TP6500DGS |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Use: |
Computer, Electric Equipment |
| Battery: |
Include |
| ATS: |
Optional |
| Alternator: |
100% Copper Wire |
| Cooling Method: |
Air Cooled |
| Stroke: |
Four Stroke |
| Installation Method: |
Portable |
| Type: |
Basic Diesel Generator |
| Output Type: |
AC Single Phase |
Product Description
Rated frequency: 50Hz or 60Hz
Rated voltage: 110/220/230/240/380V
Rated output: 4.5kw/50Hz, 5.0kw/60Hz
Power factor: 1.0
Phase: Single or 3 phase
Noise level: 72-74dB(A) @ 7m
Structure type: Silent type
Engine No: TP186FAE
Displacement: 418cc
Compression ratio: 19: 1
Fuel type: 0#(summer) -10#(winter) -35#(chiness) diesel
Lube oil type: CD grade or SAE 10W-30, 15W-40
Starting system: Electric start
Battery: Include
Voltage regulator: AVR
Wheels and handels: Include
Recoil starter: Optional
ATS: Optional
Remote control: Optional
Protection system: Low oil alarm and circuit breaker
Net weight: 170kg
Gross weight: 180kg
Overal dimension: 950*570*770mm
|
SILENT TYPE |
TP3500DGS |
TP5500DGS |
TP6500DGS |
TP7500DGS |
|
Rated frequency[Hz] |
50/60 |
|
Rated voltage[V] |
110/115/120/220/230/240,110/220,115/230,120/240 |
|
Rated output power[KVA] |
2.8/3.0 |
4.0/4.5 |
4.5/5.0 |
5.5/6.0 |
|
Max output power[KVA] |
3.0/3.5 |
4.5/5.0 |
5.0/5.5 |
6.0/6.5 |
|
Rated rotation speed[rpm] |
3000/3600 |
|
Power factor[cos@] |
1.0 |
|
Phase number |
Single phase |
|
Noise level[Db(A)@7m] |
70-74 |
|
Excitation mode |
Self-excitation brushless |
|
Engine model |
Single cylinder,4-stroke,air-cooled,direct injection, diesel engine |
|
Engine type |
178FE |
186FE |
186FAE |
188F |
|
Displacement[ml(cu/in)] |
296 |
406 |
418 |
456 |
|
Compression ratio |
20:1 |
19:1 |
|
Starting system |
Electric start |
|
Rotation dircetion |
Clockwise |
|
Fuel |
0#(summer) or -10#(winter) -35#(chillness) diesel oil |
|
Lube |
CDgrade or SAE 10W-30,15W-40 |
|
Low oil pressure alert system |
With |
|
Overall dimension(LxWxH)[mm] |
880x565x770 |
950x565x770 |
|
Dry weight[kg] |
150 |
160 |
170 |
175 |
