| Prod Model: |
DG2500/DG3500 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Cooling Method: |
Air Cooled |
| Stroke: |
Four Stroke |
| Installation Method: |
Fixed |
| Type: |
Basic Diesel Generator |
| Output Type: |
AC Single Phase |
Product Description
Our company supplys different kinds of products.High quality and favaroble price.We're pleased to get your Inquiry and we will come back to as soon as possible.We stick to the principle of "quality first, service first, continuous improvement and innovation to meet the customers" for the management and "zero defect, zero complaints" as the quality objective.
|
Engine |
Model |
DG2500 |
DG3500 |
|
Model |
170F |
178F |
|
Type |
Forced air-cooled 4-stroke OHV single cylinder |
|
Displacement(ml) |
211 |
296 |
|
Max.Output(hp) |
4.2 |
7 |
|
Starting System |
Recoil and manual-operated,power-operated |
|
|
Deameter*Stroke(mm)DxS |
70x55 |
78x62 |
|
Rated rotation speed(r/min) |
3000 |
3600 |
3000 |
3600 |
|
Rated Power(kw/ps) |
2.5/3.4 |
2.8/3.8 |
3.68/5 |
4/5.5 |
|
Fuel Consumption(g/kw/h) |
≤4.08 |
≤4.08 |
|
Crank cumgyrate direction deasil |
Viewed from flywheel |
Viewed from flywheel |
|
Lubricate Mode |
Pressure splash |
Pressure splash |
|
Fuel tank capacity(L) |
12.5 |
12.5 |
|
Continuous Operating Hours(h) |
9.5h(50Hz)//7.5h(60Hz) |
9.5h(50Hz)//7.5h(60Hz) |
|
Engine Oil Capacity |
0.75 |
1.1 |
|
Operating Noise at 7m(db) |
80(50Hz)//85(60Hz) |
83(50Hz)//86(60Hz) |
|
Generator |
Phase Number |
Single phase |
Three phase |
Single phase |
Three phase |
|
Rated Frequency(hz) |
50/60 |
50/60 |
50/60 |
50/60 |
|
Rated Voltage(v) |
220/110 |
380/220 |
220/110 |
380/220 |
|
Power Factor |
1 |
1 |
|
Rated Output(kw) |
1.8 |
2.8 |
|
Max AC Output(kw) |
2.5 |
3.5 |
|
DC Output in Low Voltage |
12V,8.3A |
12V,8.3A |
|
Packing |
Dimension LxWxH(mm) |
660x490x550 |
660x490x550 |
|
Carton |
Brown Carton |
Brown Carton |
|
N.W./G.W(kg) |
63/66 |
77/80 |
