| Prod Model: |
XD-WIND TURBINE |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Voltage: |
Customize |
| Number Of Blade: |
Multiple-Blade |
| Rotating Shaft: |
Vertical |
| Stress Way Of Blade: |
Resistance |
| Phase: |
Three Phase |
Product Description
Rated Power: 400W
Wind wheel diameter: 1.24M/1.12M
Weight: 29KG
Blade Material: Aluminum Alloy
The number of blade: 3
Minimum wind speed start: 1m/s
Minimum power wind speed: 2m/s
Minimum charge wind speed: 2.5m/s
Rated wind speed: 12m/s
Maximum cut off wind speed: 15m/s
Resistant to wind speed limit: 65m/s
The type of Generator:
Three-phase AC maglev wind turbine
Controller output voltage: 12V / 24V
Controller output current: <20AMP
Controller brake system: Over speed automatic Three-phase short-circuit braking Normal
operating temperature: -30~50 º C
| NO. | Description | Specification |
| 1 | Rated Output | 400W |
| 2 | Type of Generator | 3-Phase,AC |
| 3 | Start-up Wind Speed | 1M/s |
| 4 | Working Wind Speed | 2.7-15M/S |
| 5 | Height | 1.12M |
| 6 | Rotating Diameter | 1.24M |
| 7 | Weight | 30KG |
| 8 | Output Voltage(Controller) | DC12V/24V |
| 9 | Braking System(Controller) | Over Speed Braking by 3-Phase Short-Circuit |
| 10 | Limited Temperature | -30ºC--50ºC |
Xinda Green Energy Co., Limited is specialized in handling the business of vertical and horizontal wind turbine generator, various kind of permanent magnet generator(0.05-3000kw), speed from 20rpm-20000rpm, both vertical and horizontal, small hydro turbine system(low head and higher head), wind solar hybrid system, high efficiency high seepd permanent magnet motor, street lamp and so on
Our partner manufacturers are committed to continuously improving our operations and meeting the needs of our customers through innovation and new product development. We work closely with them to optimize the performance and cost-effectiveness of their processes.
