| Price: | US $ 520/Piece |
|---|---|
| Trade Terms: | FOB,CFR,CIF |
| Min Order: | 5/Piece |
| Pay Type: | L/C,T/T |
| Prod Model: | SG6500SE, SG5500SE |
|---|---|
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Sg65oose: | 5kw |
| Sg5500se: | 4.5kw |
| Type: | Micro-Computer Control Automatic Diesel Generator |
| Installation Method: | Fixed |
| Stroke: | Four Stroke |
| Cooling Method: | Air Cooled |
| Output Type: | AC Three Phase |
| Speed: | High Speed |
Diesel Generator (02) (SG6500SE)| Model no: : Rated frequency (Hz) Rated voltage (V) Rated current (A) Rated output power (KW) Max output power(KW) Rated rotation speed (rpm) DC output Power factor (cos? ) | SG6500SE 50 60 230 240/120 21.7 22.9/45.8 5.0 5.5 5.5 6 3000 3600 12V 8.3A 1.0 |
| Phase number Noise level [dB(A)@ 7m ] Overall dimension (LxMxH)[mm(in)] Dry weight [kg(lbs. )] Structure type Excitation mode | Single phase 70-74 910x530x740 (35.83x20.87x29.13) 165(363) Silent type Self-excitation and constant voltage |
| Engine model Engine type Displacement [ml(cu. in)] Compression ratio Rated power [KW(Hp)/rpm] | SR186FA Single cylinder, 4-stroke, air-cooled, direct injection, diesel engine 418 (25.51) 19 1 5.9(8.02)/3000 6.5(8.84)/3600 |
| Starting system Rotation direction (View from flywheel) Fuel Lube Low oil pressure alert system | 12Velectric starter Clockwise 0#(summer)-10#(winter) light diesel oil SAE10W30 (above CC grade) With |
