| Prod Model: |
YC4D100Z-C20 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Start: |
Electric Start |
| Place Of Original: |
China |
| Warranty: |
18 Months |
| Certification: |
CCS |
| Displacement (L): |
4.214 |
Product Description
We specialize in original YUCHAI Marine diesel engine.include YC6C,YC6T,YC6A,YC6B,YC4D,YC4F series.
YC4D YUCHAI marine engine for small fish boat,power at 24~40kw.low fuel consumption,High reliability,long life,with 18 month warranty. such as YC4108CA,YC4108C,YC4D55C,YC41D80-C20,YC4108ZC,YC4D75C,YC4D100Z-C20,YC4D120Z-C20. Using alloy cast iron body, cylinder head and reinforcement degree is high, the whole crankshaft, sliding bearing, the small size light weight, high reliability.
Welcome to inquiry!
YC4D yuchai marine engine model| Model | YC4108CA | YC4108C | YC4D55C | YC4D80-C20 |
|---|
| Type | Vertical, in-line, water-cooled, four stroke |
| Intake way | Natural aspirated |
| No. of cylinders - Bore × Stroke (mm) | 4-108×115 |
| Displacement (L) | 4.214 |
| Compression ratio | 17:01 |
| Continuous power /speed (kW (Ps)/r/min) | 32 (45)/1500 | 40 (55)/1500 | 40 (55)/1800 | 58 (80)/2400 |
| One-hour power/speed (kW (Ps)/r/min) | 35.2 (50)/1548 | 44 (60)/1548 | 44 (60)/1858 | 63.8 (85)/2478 |
| Min. specific fuel consumption | ≤200 |
| (g/kW·h) |
| Specific oil consumption | ≤0.8 |
| (g/kW·h) |
| Crankshaft rotation direction (seen from power output end) | Anticlockwise |
| Starting way | Electrical |
| Net weight (kg) | 370 |
| Overall dimensions (LxWxH) | 986×730×948 |
| (mm) |
| Certificate | ZC,CCS |
| Model | YC4108ZC | YC4D75C | YC4D100Z-C20 | YC4D120Z-C20 |
|---|
| Type | Vertical, in-line, water-cooled, four stroke |
| Intake way | Turbo charged |
| No. of cylinders - Bore × Stroke (mm) | 4-108×115 |
| Displacement (L) | 4.214 |
| Compression ratio | 17:01 |
| Continuous power /speed (kW (Ps)/r/min) | 50 (70)/1500 | 55 (75)/1800 | 75 (100)/2400 | 90 (120)/3000 |
| One-hour power/speed (kW (Ps)/r/min) | 55 (75)/1548 | 60.5 (80)/1858 | 82.5 (110)/2478 | 99 (135)/3096 |
| Min. specific fuel consumption (g/kW·h) | ≤198 |
| Specific oil consumption (g/kW·h) | ≤0.8 |
| Crankshaft rotation direction (seen from power output end) | Anticlockwise |
| Starting way | Electrical |
| Net weight (kg) | 390 |
| Overall dimensions (LxWxH) (mm) | 986×730×1254 |
| Certificate | ZC,CCS |
If you have any demand for yuchai marine engine,please feel free to contact with me.
Comfort diesel power Limited was found in 2005. As one of the leading diesel service company, We built up good relation with many famous engine manufacturer and supply complete engine as Cummins, MWM, Isuzu, Iveco, VM, Shanghai diesel, Weichai, Yuchai etc. Which are used for Maine, off-road, trucks, bus, ming application. For spare parts business, we supply genuine and OEM parts for all most engine models, with high quality and competitive price.
Now we are looking into a strategic to cooperate with some European company to develop our own engine brand with high lightening engines for global market. And develop a professional service team to crate a comfort feeling of using our engines. This is the principle of Comfort Diesel.
